• Easy and quick wireless installation
• All cameras can be linked with NVS at one time
• Secure and integrated video storage, all videos are stored in NVS
• Up to 512 GB Micro SD card storage capacity
• Remote mobile phone management, all functions can be performed through Hik-Connect, such as camera adding, two-way audio, live view, playback, etc.
• Accurate motion detection function
• Smart IR and white light
• Built-in mic and speaker for two-way audio
• 1 fixed PT turret camera and 1 fixed Speed Dome camera, both with 2 MP resolution and 2.8 mm focal length

Camera

• Lens
• Focal Length : 2.8 mm
• Aperture : F2.0
• Focus : Fixed
• FOV Horizontal FOV 101°, vertical FOV 56°, diagonal FOV 118°

IR

• IR Range
  • Bullet:Up to 30 m
  • Dome:White light distance: up to 25 m,IR distance: up to 25 m

Compression Standard

• Video Compression : H.265,H.264,MJPEG
• H.264 Type : Baseline Profile/Main Profile/High Profile
• H.265 Type Main Profile
• Video Bit : Rate 32 Kbps to 8 Mbps
• Audio Compression : G.711/AAC-LC
• Audio Bit Rate : 64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
• Audio Sampling Rate : 8 kHz/16 kHz
• Environment Noise Filtering : Yes


• Max. Resolution : 2MP
• Main Stream
  • 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 768 x 432)
  • 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 768 x 432)
• Sub-stream
  • 50 Hz: 25 fps (768 × 432)
  • 60 Hz: 30 fps (768 × 432)
• Image Setting : Saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
• Day/Night : Switch Auto/Scheduled/Day/Night

Network

• Alarm Trigger : Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
• Protocols : TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv6, UDP, QoS, UPnP
• General Function : One-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

Interface

• Communication Interface : 1 RJ45 10M/100M self-adaptive Ethernet port
• Reset Button : Yes

General

• Power Supply
  • Bullet: 12 VDC ± 25%, 0.5 A, max. 6 W,Ø 5.5 mm coaxial power plug,reverse polarity
    protection,A switching adapter is included in the package.
  • Dome: 12 VDC ± 25%, reverse polarity protection, 0.75 A, max. 9 W, Ø 5.5 mm coaxial
    power plug
• Consumption
  • Bullet: ≤ 6 W
  • Dome: ≤ 9 W
• Working Temperature
  • Bullet: -30 °C to 60 °C (-22 °F to 140 °F)
  • Dome: -10 °C to 40 °C (-14 °F to 104 °F)
• Working Humidity  : 95% or less (non-condensing)
• Dimension (W × D × H)
  • Bullet: 260.9 mm × 113.9 mm × 67.4 mm (10.3" × 4.5" × 2.7")
  • Dome: Ø 124 mm × 119 mm (Ø 4.89" × 4.68")
• Weight
  • Bullet: 305 g (0.67 lb.)
  • Dome: 600 g (1.32 lb.)

Others

• Camera Case Type : Bullet, Dome
• Image Sensor : 1/3" Progressive Scan CMOS
• Min. Illumination
  • Bullet:Color: 0.01 Lux @ (F2.0, AGC ON),B/W: 0 Lux with IR
  • Dome:Color: 0.04 Lux @ (F2.0, AGC ON),B/W: 0.01 Lux @ (F2.0, AGC ON),0 Lux with IR
• Day &Night : IR cut filter
• WDR : DWDR
• Angle Adjustment
  • Bullet: Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
  • Dome: Pan: 0° to 345°,tilt: 0° to 80°
• Protection Level : IP66
• Wi-Fi Support : Yes

NVS

Video and Audio

• IP Video Input : 4-ch
• Incoming/Outgoing Bandwidth : 20 Mbps/20 Mbps

Decoding

• Video Resolution 6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
• Synchronous Playback 1-ch

Network

• Network Interface 1, RJ45 10/100M Ethernet interface

Wi-Fi

• Frequency Band 2.4 GHz
• Antenna Structure High gain antenna
• Transmission Speed 150 Mbps
• Transmission Standard IEEE 802.11b/g/n/ax

Auxiliary Interface

• SD Card 32G/64G/128G/256G/512G

General

• Power Supply : 12 VDC
• Consumption (without HDD and

  • PoE off)
  • ≤ 6 W
• Working Temperature : -10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity : 10% to 90%
• Dimension (W × D × H) : 163 x 125 x 26 mm (6.4" × 4.9" × 1.0")
• Weight (without hard disk) : ≤ 500g

Kit

• Accessories
  • Power adaptor: 2 × IPC power adaptor, 1 × NVS power adaptor
  • Ethernet cable: RJ45, Cat5e UTP, 1 m
