Smart Energy Meter & Timer, 50/60Hz, Rated Current:65A , 9600W (Resistive Load), 110V/220V, kWh Accuracy:Class1, Voltage/Current Circuit:<1.5VA/<2W/8VA, 0.004Ib(20mA), LCD:99999.9kWh, WIFI:802.11B/G/N, Only Supports 2.4GHZ Network, Bluetooth V5.2
Smart Energy Meter & Timer
Overview
The MTS21 Smart energy meter & timer is specifically designed to measure active and reactive energy for single-phase two-wire systems and various parameters. This smart device is equipped with Wi-Fi connectivity, allowing users to utilize the free “Major Tech Hub” Smart App for remote monitoring and control. It adheres to Wi-Fi 802.11b/g/n standards for seamless data communication. When installing the smart device, ensure that this is done by a qualified professional in accordance with South African regulations and making sure it is placed in an appropriate environment with an ambient temperature range of -25°C to 55°C. The relative humidity should be kept below 75%. The manufacturing of this device aligns with international standards, including IEC62052-11 for General Requirements for Electricity Metering Equipment (AC) and IEC62053-21 for Static meters/timers for Active Energy (Classes 1 and 2). Features: Provides in-depth analysis of energy consumption via the smart app Displays Voltage, Current, Active Power, Power Factor and Frequency Load Protection – the app can be set to alert and trigger an automatic device shutdown Din Rail Compatible (35mm) Dual Mode: Wi-Fi and Bluetooth
Specifications
- Rated Frequency : 50/60 Hz
- Rated Current : 65A
- Power : 9600W (Resistive Load)
- Rated Voltage : 110V/220V
- Voltage Range : 90 - 260V
- Approvals : IEC/SANS / ICASA / LOA
- kWh accuracy : Class 1
- R.M.S accuracy : Class 0.5
- Current circuit : <1.5VA
- Voltage circuit : <2W/8VA
- Starting Current : 0.004Ib(20mA)
- LCD : 99999.9kWh
- WIFI
- 802.11B/G/N, ONLY SUPPORTS
- 2.4GHZ NETWORK,NOT SUPPORTED
- ON 5GHZ NETWORK
- Operation Temp. : -25◦ to +55◦
- Bluetooth : Version 5.2
Downloads
Additional Information
Device |
Meter & Timer |
Type |
Smart | Energy |
