TVT TD-2008NS-HL-L

Name: TVT TD-2008NS-HL-L - Communica [Part No: TVT TD-2008NS-HL-L]
Brand: TVT
SKU: TVT TD-2008NS-HL-L
Price: 1450 ZAR
Availability: InStock

SKU: TVT TD-2008NS-HL-L

BRAND: TVT

In Stock
R 1,667.50_{(inc VAT)}
R 1,450.00_{(ex VAT)}

Collections: Security, Access Control & Surveillance

Type: CCTV Products & Accessories

Category: DVR

DVR 8CH Hybrid H.265, Video I/P 8xBNC, 5MP Up to 5MP@25fps, TVI/ AHD/CVI 1080P Lite/ 720P/ 720P Lite/WD1, RJ45 100Mbps×1, SATA×1, Up to 8TB, USB2.0×2, Audio I/P:RCA×1, O/P1xRCA, HDMI/VGA, PSU:12VDC 1.5A

4/8 CH Hybrid DVR

Overview

TD-2004/08NS-HL-L is a 4/8 CH 720P high definition DVR with ability to connect analog and IP cameras simultaneously, which adopts the standard H.265 high profile compression format and the advanced SOC technique to ensure real time recording in each channel and realize outstanding robustness of the system. TD-2004/08NS-HL-L supports 4 /8CH video input, 1 CH audio input, simultaneous 4 /8 CH playback. The series of product can meet different security requirements of home, financial, commerce, enterprise, transportation and government, etc.

Feature(s)

4/8 CH TVI / AHD/CVI 1080P/1080P Lite/720P/WD1 video input
4 CH DVR supports 2 CH 1080P / 960P /720P IP video input
8CH DVR supports 8CH 5MP/4MP/3MP/1080P / 960P /720P IP video input
Adopt standard H.265 high profile compression format to get high-quality video at much lower bit rate
Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
Multi-mode recording: manual / timed / motion / AI recording
Playback : 4 /8CH simultaneously playback
Search: time slice, time, event, tag search
Express and flexible backup via USB, network and so on
Pentaplex: preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol
Remote control via Web or CMS : preview, playback, backup, PTZ and configuration
Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
Authorization management, log review and device status review
Support 1080P output, true high resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QRCode scanning by mobile phones
Powerful mobile surveillance by smart phones with iOS and Andriod OS

Specifications

System	OS	Embedded Linux
Video	Analog Video Input	BNC × 4	BNC × 8
		BNC interface (1.0Vp-p; 75Ω)
		TVI/ AHD/CVI: 1080P/ 1080P Lite/ 720P/ 720P Lite/ WD1
	IP Video Input	2CH	2CH
		Up to 2MP@30fps	Up to 5MP@25fps
	Total Input	6CH	10CH
	Output	HDMI × 1 :1920 × 1080 / 1280 × 1024 / 1024 × 768
		VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
	Compression	H.264/H.265
	Multi-screen Display	1/4/6/9	1/4/6/8/9/13/16
Audio	Input	RCA ×1
	Output	RCA × 1 (linear, 600Ω)
	Two-way audio	Take up channel one audio input
	Compression	G.711(U/A)
Record	Resolution	1080P Lite/ 720P/ 720P Lite/ WD1
	Frame Rate	Analog Channel:
		4CH DVR: 1080P Lite/720P/WD1: 25fps (PAL)/30fps (NTSC)
		8CH DVR: 1080P Lite/720P/WD1: 25fps (PAL)/30fps (NTSC) ( only CH 1 supports) 1080P Lite/720P/WD1: 12fps (PAL)/15fps (NTSC) ( other channels support) 720P Lite: 25fps(PAL) / 30fps (NTSC)
		IP Channel: 25fps(PAL) / 30fps (NTSC)
	Bit Rate	32Kbps ~ 4Mbps
Playback	Playback	4 CH	8CH
	Search	Time slice / time / event / tag search
	Smart Search	Highlight colors to display the camera record in a certain period of time, different colors refer to different record events
	Function	Play, pause, FF, FB, digital zoom, etc.
Alarm	Mode	Manual, motion, exception, smart event
	Input	No
	Output	No
Network	Interface	RJ 45 100Mbps × 1
	Protocol	TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, HTTP, HTTPs, NTP, SMTP
	Incoming Bandwidth	10Mbps	16Mbps
	Outgoing Bandwidth	30Mbps	60Mbps
	Client Connection	Max. 5 users access
MobileDevice	OS	iOS, Andriod
Storage	HDD	SATA× 1, up to 8TB
Backup	Local Backup	U disk, USB mobile HDD
	Network Backup	Yes
Port	RS 485	No
	USB	USB 2.0 × 2
	Remote Controller	No
Others	Power Supply	DC12V / 1.5A
	Consumption	≤ 5W ( without HDD )
	Dimensions(mm)	255 × 222 × 42 ( W × D × H )
	Working Environment	-10~50°C, 10%~90% (humidity)
	Certificate	CE, FCC
	Environment Protection	Directive EU RoHS, WEEE, REACH

Downloads

Datasheet - TVT TD-2008NS-HL-L

Additional Information

Device	DVR
Type	4/8 CH \| Hybrid
