• Brings Wi-Fi dead zones to life with strong Wi-Fi expansion at a combined speed of up to 750Mbps*
• Operates over both 2.4GHz band(300Mbps) and 5GHz bands(433Mbps) for a more stable wireless experience
• Intelligent signal light helps to fi­nd the best location for optimal Wi-Fi coverage by showing the signal strength
• Works with any Wi-Fi router or wireless access point**

Hardware Features

• Plug Type : US
• Standards and Protocols : IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b
• Interface : 1 x 10/100M Ethernet Port (RJ45)
• Button : WPS Button, Reset Button
• Power Consumption : 7.3W (max power consumption)
• Dimensions ( W x D x H ) : 3.1 x 3.0 x 3.0 in. (80 x 78 x 77mm)
• Antenna : 2 x external

Wireless Features

• Frequency : 2.4GHz & 5GHz(11ac)
• Signal Rate
• 5GHz:Up to 433Mbps
• 2.4GHz:Up to 300Mpbs
• Reception Sensitivity
• 5GHz:
• 11a 6Mbps: -94dBm@10% PER
• 11a 54Mbps: -77dBm@10% PER
• 11ac HT20: -69dBm@10% PER
• 11ac HT40: -66dBm@10% PER
• 11ac HT80: -63dBm@10% PER
• 2.4GHz
• 11g 54Mbps: -79dBm@10% PER
• 11n HT20: -77dBm@10% PER
• 11n HT40: -74dBm@10% PER
• Wireless Modes
• Range Extender/Access Point
• Wireless Statistic
• Concurrent Mode boost both 2.4G/5G Wi-Fi band
• Wireless Functions
• Wireless Statistic
• Concurrent Mode boost both 2.4G/5G Wi-Fi band
• Access Control
• LED Control
• Domain Login Function
• Wireless Security
• 64/128-bit WEP
• WPA-PSK / WPA2-PSK
• Transmission Power :
• <19.5dBm(2.4GHz)
• <19.5dBm(5GHz)

Others

• Certification : FCC, RoHS
• Package Contents : AC750 Wi-Fi Range Extender RE205, Quick Installation Guide
• Box Dimensions (W X D X H) : 6.15 x 4 x 3.7 in. (156.5 x 101.5 x 95mm)
• System Requirements : Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
• Environment
• Operating Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -40°C~70°C (-40°F~158°F)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
