MS3121E-14-15P

Name: MS3121E-14-15P - Communica [Part No: MS3121E-14-15P]
Brand: Souriau
SKU: MS3121E-14-15P
Price: 684 ZAR
Availability: InStock

SKU: MS3121E-14-15P

BRAND: Souriau

R 786.60_{(inc VAT)}
R 684.00_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Connectors

Type: MIL-Spec / MIL-Type

Category: Circular MIL DTL 26482 Connectors

Circular Connector MIL-DTL-26482 Series 1 Style Bayonet Lock Cable End Receptacle, Male 15 Pole 14* #20/1* #16 Crimp Contact 7,5A/22A 600VAC/850VDC (KPSE01E-14-15P)(PT01E14-15P)(85101R1415P50)

Circular Connector MIL-DTL-26482 Series 1

Specifications

Circular Connector Shell Style: Cable Mount Receptacle
No. of Contacts: 15Contacts
Circular Contact Type: Solder Pin
Coupling Style: Bayonet
Insert Arrangement: 14-15
Connector Body Material: Aluminium Alloy Body
Connector Body Plating: Olive Drab Chromate over Cadmium
Contact Material: Copper Alloy
Contact Plating: Gold
Insert Rotation: N
Service Class: Environmentally Sealed
Equivalent Military Specification: MIL-DTL-26482 Series I

Additional Information

Device	Connector
Type	Circular \| MIL-DTL-26482 \| Series 1

Upgrade your connections with the MS3121E-14-15P Circular Connector, designed for durability and reliability in demanding environments. This military-grade, bayonet lock receptacle features 15 solder pin contacts, ensuring a secure connection for your applications. With its environmentally sealed design and high-quality aluminum alloy construction, this connector delivers exceptional performance at 600VAC/850VDC. Choose the MS3121E for dependable connectivity you can trust.
