·        Manufacturer: Siemens;

·        Part Number: 3RT2036-1AF00;

·        Product Family: SIRIUS 3RT20;

·        Module Type: Power Contactor;

·        Contactor Size: S2;

·        Number of Poles: 3-pole;

·        Main Contacts: 3 NO (Normally Open);

·        Auxiliary Contacts: 1 NO + 1 NC (integrated);

·        Rated Operational Current (AC-3): 50–51 A;

·        Rated Operational Voltage: Up to 690 V AC;

·        Rated Motor Power:

·        22 kW @ 400 V AC;

·        15 HP @ 230 V;

·        40 HP @ 460 V;

·        Control (Coil) Voltage: 110 V AC (50 / 60 Hz);

·        Auxiliary Contact Current: 10 A;

·        Terminal Type: Screw terminals;

·        Mounting Type: DIN rail or panel mounting;

·        Operating Temperature Range: −25 °C to +60 °C;

·        Insulation Voltage: 690 V;

·        Weight (Approx.): ~0.98 kg;

·        Standards Compliance: IEC 60946;

·        Typical Application: Industrial motor control, starter assemblies, and switching of three-phase motors;
