Current/Voltage Measuring Module Set Current 63...630 A Voltage Measurement up to 690 V, Overall Width 145 MM, Busbar Connection
Current/Voltage Measuring Module
Specifications
- Product Name: SIMOCODE pro Digital Module (Expansion)
- Model Number: 3UF7114-1BA01-0
- Product Family: SIMOCODE pro 3UF7 Motor Management & Control Devices
- Function: Digital I/O expansion module
- Digital Inputs: 8 × digital inputs
- Digital Outputs: 4 × digital outputs (high-side)
- Relay Outputs: 2 × relay outputs
- Input Supply Voltage: AC/DC 24 V (control supply)
- Rated Control Supply Current: Approx. 50 mA (typical)
- Input Logic Levels: Defined logic HIGH/LOW per Siemens standard
- Output Current (High-side): Up to 0.5 A per output (typical, verify exact value)
- Relay Contact Rating: Standard industrial relay ratings
- Protection Class: IP20
- Operating Temperature: –25 °C to +60 °C
- Storage Temperature: –40 °C to +80 °C
- Shock Resistance: Per IEC standard (e.g., 15 g / 11 ms)
- Vibration Resistance: Per IEC standard (1–6 Hz / 15 mm; 6–500 Hz / 2 g)
- Connection Method: Screw terminals
- Mounting Type: DIN-rail mounted or snap-on
- Typical Applications: Expansion of digital I/O for SIMOCODE pro basic units
- Weight : Approx. 0.15-0.2 kg
- Width: Approx. 22.5 mm (1 modular width)
- Country of Origin: Germany or EU region
Downloads
Additional Information
| Device |
Measuring Module |
| Type |
Current/Voltage | Measuring | Module |
Enhance your electrical system's efficiency with the 3UF7114-1BA01-0 Current/Voltage Measuring Module. Capable of measuring currents from 63 to 630 A and voltages up to 690 V, this reliable module ensures precise monitoring for optimal performance. It's designed for easy busbar connection and fits seamlessly into your setup, providing essential data to help you make informed decisions and improve safety.
