8601QE

Name: 8601QE - Communica [Part No: 8601QE]
Brand: Communica
SKU: 8601QE
Price: 57.15 ZAR
Availability: InStock

SKU: 8601QE

BRAND: Communica

R 65.72_{(inc VAT)}
R 57.15_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Electromechanical

Type: Switches

Category: Toggle Switches

SPDT Snap Acting Push Button Switch with On-On Latch and Vertical Solder-Lug; Actuator : 5.54 High, Contact Rating : 3A-120VAC/28VDC,1A-250VAC

Overview

Features

Specification

Contact Rating: 3A-120VAC/28VDC,1A-250VAC
Mechanical Life: 50,000 make-and-break cycles
Contact Resistance: 20mΩ max. initial @ 2-4VDC, 100mA for both silver and gold plated contacts
Insulation Resistance: 1,000MΩ min
Dielectric Strength: 1,000 Vrms min.@sea level
Operating Temperature: -30°C to 85°C
Materials :
- Case: Diallyl phthalate(DAP) (UL94V-0)
- Plunger: Glass filled Nylon or Glass filled polyester
- Bushing: Brass,nickel plated
- Housing: Stainless Steel
- Contact Material: Sliver

Transition Style	Latching
Actuator Style	Standard-Lever
Termination	Solder-Lug
Electrical Rating	3A-120VAC/28VDC \| 1A-250VAC
Size	12.7x6.9

Discover the 8601QE SPDT Snap Acting Push Button Switch, designed for durability and reliability with a contact rating of 3A-120VAC. Its compact size and robust materials ensure long-lasting performance, making it ideal for various applications. Enhance your projects with this versatile, latching switch that operates smoothly in challenging conditions.
