Medium Power Sub Mini Sealed Relay Form 1C (1c/o) 7.6mm Contact Spacing 24VDC 2800 Ohm Coil 3A 250VAC/30VDC Max
Medium Power Sub Mini Sealed Relay
Features
- Provide 5A 250VAC to meet 300000 switching capability specifications
- Creepage distance: 8mm (coil & contacts)
- Clearance distance: NO type 4.5mm, NC type 4mm
- 1 Form A、1 From B and 1 Form C configurations
- Subminiature, standard PCB layout
- Plastic sealed and flux proofed types available
- UL insulation system: Class F available
- Product in accordance to IEC 60335-1 available.
Downloads
Additional Information
Device |
Relay |
Type |
Medium Power Sub | Mini | Sealed |
Contact Form |
Form 1C |
Coil Rated Voltage |
24V |
Max. Switching Current |
3A |
Coil Resistance |
2800Ω |
