IAR3F1200

Name: IAR3F1200 - Communica [Part No: IAR3F1200]
Brand: Apem
SKU: IAR3F1200
Price: 369 ZAR
Availability: InStock

SKU: IAR3F1200

BRAND: Apem

R 424.35_{(inc VAT)}
R 369.00_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Electromechanical

Type: Switches

Category: Pushbutton Switches

2A 24VDC IP67 Low Profile Push Button Switch with Round Black Actuatorl

Overview

Features

Resistant to frost, sand and hydrocarbons
Tactile feedback
Front panel sealed to IP65 and IP67

Specification

Max. current/voltage rating with resistive load : 2A 24VDC
Initial Contact Resistance : 100mΩ max.
Insulation Resistance : 100 MΩ min. at 500VDC
Dielectric Strength : 500 Vrms
Electrical Life at Full Load : 1.000.000 cycles
Panel Thickness : 7 mm (.276) max.
Total Travel : 1,5 mm (.059)± 0,3 mm
Typical Operating Force : 7N ±2N
Low Level or Mechanical Life : 1.000.000 cycles
Torque : 0.5 to 1Nm max. applied to nut

Transition Style	Momentary
Actuator Style	Push Button
Termination	Flying Leads
Switch Circuit	MOM N/O
Electrical Rating	2A 24VDC
Actuator Colour	Black
IP Rating	IP67

Downloads

Datasheet Download

The IAR3F1200 is a durable low-profile push button switch designed for tough environments, featuring an IP67 rating for maximum protection against dust and water. With tactile feedback and a long lifespan of 1,000,000 cycles, it delivers reliable performance in any application. Upgrade your control system with this robust, easy-to-use switch, perfect for both professional and DIY projects.
