NC4D-JP-DC12V

Name: NC4D-JP-DC12V - Communica [Part No: NC4D-JP-DC12V]
Brand: Panasonic
SKU: NC4D-JP-DC12V
Price: 215 ZAR
Availability: InStock

SKU: NC4D-JP-DC12V

BRAND: Panasonic

R 247.25_{(inc VAT)}
R 215.00_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Electromechanical

Type: Relays

Category: Power Relays

Medium Power Relay • Form 4C • VCoil= 12V DC • IMax Switching= 5A • RCoil= 200Ω • PCB • Horizontal Case

Overview

Features

Bifurcated Contacts
Horizontal Case

Specification

Model	NC4D-JP-DC12V
Contact Form	Form 4C
Size Category	Std Size
Size	38x25x11mm
Termination	PCB
Coil Rated Voltage	12V
AC/DC Voltage	DC
Max. Switching Current	5A
Electrical Rating	5A/250VAC
Coil Power	720mW Power
Coil Resistance	200Ω
Isolation Voltage	2KV
Approvals	UL/CSA
Contact Material	Ag
No. of Pins	14 Pin(s)
No. of Poles	4 Pole(s)

Downloads

Datasheet Download

The NC4D-JP-DC12V medium power relay offers reliable performance with a 12V DC coil and a maximum switching current of 5A. Its compact design and bifurcated contacts ensure efficient operation, making it ideal for PCB applications. Enhance your projects with this UL/CSA approved relay that guarantees durability and safety.
