• Nominal Voltage : 12V
• Rated Capacity (20hr Rate) : 200Ah
• Dimensions
• Length : 20.63inches (524mm)
• Width : 9.41inches (239mm)
• Height : 8.58inches (218mm)
• Total Height : 8.90inches (226mm)
• Weight : Approx. 0.49kg

Characteristics

• Capacity 77°F(25°C)
• 20hour rate (10.0 A) : 200Ah
• 10hour rate (18.0 A) : 180Ah
• 5hour rate (34.0 A) : 170Ah
• 1hour rate (130 A) : 130Ah
• Internal Resistance
• Full Charged, 77°F(25°C) : 4mΩ
• Affected By Temperature (10hr Rate)
• 104°F(40°C) : 102%
• 77°F(25°C) : 100%
• 32°F(0°C) : 85%
• 5°F(-15°C) : 65%
• Self-Discharge 77°F(25°C)
• Capacity after 3 month storage : 90%
• Capacity after 6 month storage : 85%
• Capacity after 9 month storag : 65%

Charge (Constant Voltage)

• Initial Charge Current “LESS” than 0.42A
• Cycle : 14.2–14.5V/77°F(25°C)
• Stand By : 13.4–13.7V/77°F(25°C)
