LIF480-10B24R2

Name: LIF480-10B24R2 - Communica [Part No: LIF480-10B24R2]
Brand: Mornsun
SKU: LIF480-10B24R2
Price: 2364.50 ZAR
Availability: InStock

SKU: LIF480-10B24R2

BRAND: Mornsun

R 2,719.18_{(inc VAT)}
R 2,364.50_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Power

Type: Power Supplies

Category: Din Rail Power Supply, Switch Mode Power Supplies

DIN Rail Metal Case Slim Profile Switch Mode Power Supply with Active PFC. Input: 85 ~ 264VAC/120 - 370VDC. Output 24VDC @ 20A Hi Reliability

Slim Profile Switch Mode Power Supply

Feature

Universal 85- 264VAC or 120- 370VDC Input voltage
Accepts AC or DC input (dual-use of same terminal)
Operating ambient temperature range: -40℃ to +70℃
The efficiency is up to 94.5%
High I/O isolation test voltage up to 3000VAC
DC OK function
Active PFC, PF > 0.99
Low ripple & noise
Output short circuit, over-current, over-voltage,
over-temperature protection, input undervoltage
protection
DIN rail TS-35/7.5 or 15 mountable
Ultra slim design with 48mm width
Withstand 305VAC input voltage 5S
Safety according to IEC/UL62368, EN61558

Additional Information

Device	Power Supply
Type	Slim Profile \| Switch Mode
Input Voltage	85 ~ 264VAC/120 - 370VDC
Output	24VDC @ 20A
Size	W-48mm x H-132mm x D-125mm

Upgrade your power solutions with the LIF480-10B24R2 Slim Profile Switch Mode Power Supply. Engineered for reliability, this compact unit delivers 24VDC at 20A with a remarkable efficiency of 94.5%, ensuring optimal performance in diverse environments. Its versatile input range and robust protection features make it the ideal choice for your DIN rail applications. Experience exceptional quality and peace of mind with this high-performance power supply.
