LM200-10B05

Name: LM200-10B05 - Communica [Part No: LM200-10B05]
Brand: Mornsun
SKU: LM200-10B05
Price: 547.47 ZAR
Availability: OutOfStock

SKU: LM200-10B05

BRAND: Mornsun

Sold Out
R 629.59_{(inc VAT)}
R 547.47_{(ex VAT)}

Collections: Power

Type: Power Supplies

Category: Metal Case Power Supply, Switch Mode Power Supplies

Metal Case Small Outline Switch Mode Power Supply Input: 180 ~ 264VAC (Switch)/240 - 370VDC. Output 5VDC @ 30A. Terminal Block Term.

Small Outline Switch Mode Power Supply

Feature

Selectable AC input range: 90 - 132VAC/180 - 264VAC
DC input range: 240 - 370VDC(Switch in position of 230)
Ultra low standby power consumption < 0.75W
@230VAC
Operating ambient temperature range: - 30℃ to +70℃
High efficiency, high reliability
LED indicator for power on
Output short circuit, over-current, over-voltage,
over-temperature protection
Operating altitude up to 5000m
Safety according to EN60335, EN61558

Downloads

Datasheet - LM200-10B05

Additional Information

Device	Power Supply
Type	Small Outline \| Switch Mode
Input Voltage	180 ~ 264VAC (Switch)/240 - 370VDC
Output	5VDC @ 30A
Size	179.00 x 99.00 x 30.00mm

The LM200-10B05 is a compact switch mode power supply that delivers reliable 5VDC at 30A, perfect for various applications. With its wide input voltage range and exceptional efficiency, it minimizes energy consumption while ensuring safety with built-in protections. Enjoy peace of mind with an operating temperature range of -30℃ to +70℃ and an LED power indicator for easy monitoring. Upgrade your setup with this high-performance power supply today!
