LM75-23B55

Name: LM75-23B55 - Communica [Part No: LM75-23B55]
Brand: Mornsun
SKU: LM75-23B55
Price: 362.76 ZAR
Availability: InStock

SKU: LM75-23B55

BRAND: Mornsun

R 417.17_{(inc VAT)}
R 362.76_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Power

Type: Power Supplies

Category: Metal Case Power Supply, Switch Mode Power Supplies

Metal Case Switch Mode Power Supply Input: 85 ~ 305VAC/120 - 430VDC. Output 55VDC @ 1,36A. Terminal Block Term. 4KVAC Isolation (LRS-75-55) (Metal Case 55V - 1,36A)

Small Outline Switch Mode Power Supply

Feature

Universal 85 - 305VAC or 120 - 430VDC Input voltage
Accepts AC or DC input (dual-use of same terminal)
Operating ambient temperature range: -30℃ to +70℃
Low standby power consumption, high efficiency
High I/O isolation test voltage up to 4000VAC
Low ripple & noise
Output short circuit, over-current, over-voltage
protection
Over-voltage class Ⅲ
Operating altitude up to 5000m

Downloads

Datasheet - LM75-23B55

Additional Information

Device	Power Supply
Type	Small Outline \| Switch Mode
Input Voltage	85 ~ 305VAC/120 - 430VDC
Output	55VDC @ 1,36A
Size	99.00 x 97.00 x 30.00 mm

Discover the LM75-23B55 Switch Mode Power Supply, designed for versatility with universal input voltage and reliable 55VDC output. Its compact metal case ensures durability while providing low standby power consumption and efficient performance. With robust protection features and a wide operating temperature range, this power supply is perfect for various applications, delivering consistent power when you need it most.
