VICT BLUESOLAR MPPT100/50

SKU: VICT BLUESOLAR MPPT100/50

BRAND: Victron


Victron Bluesolar Charge Controller 12/24V 50A

Bluesolar Charge Controller

Specifications

  • BlueSolar Charge Controller : MPPT 100/50
  • Battery voltage : 12/24V Auto Select
  • Rated charge current : 50A
  • Nominal PV power, 12V 1a,b) : 700W
  • Nominal PV power, 24V 1a,b) : 1400W
  • Maximum PV open circuit voltage : 100V
  • Max. PV short circuit current 2) : 60A
  • Maximum efficiency : 98%
  • Self-consumption : 24V: 20 mA
  • Charge voltage 'absorption' : Default setting: 14,4V / 28,8V (adjustable)
  • Charge voltage 'float' : Default setting: 13,8V / 27,6V (adjustable)
  • Charge algorithm : multi-stage adaptive
  • Temperature compensation : -16 mV / °C resp. -32 mV / °C
  • Operating temperature : -30 to +60°C (full rated output up to 40°C)
  • Humidity : 95%, non-condensing
  • Data communication port : VE.Direct
  • Colour : Blue (RAL 5012)
  • Power terminals : 16 mm2 / AWG6
  • Protection category : IP43 (electronic components), IP22 (connection area)
  • Weight : 1,3 kg 1,3 kg
  • Dimensions (h x w x d) : 130 x 186 x 70 mm 130 x 186 x 70 mm

Downloads

Additional Information

Device Charge Controller
Type Bluesolar
