Camera
|
|
Image Sensor
|
1/1.8" CMOS
|
|
Max. Resolution
|
2688 (H) × 1520 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
256 MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
0.0001 lux@F1.0
|
|
S/N Ratio
|
>56 dB
|
|
Illumination Distance
|
Up to 50 m (164.04 ft) (Warm light)
|
|
Illuminator On/Off Control
|
Auto;Manual
|
|
Illuminator Number
|
4 (Warm light)
|
|
Angle Adjustment
|
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M16
|
|
Focal Length
|
2.8 mm
|
|
Max. Aperture
|
F1.0
|
|
Field of View
|
2.8 mm: H: 105°; V: 57°; D: 125°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 2.0 m (6.56 ft)
|
|
DORI Distance
|
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
57.9 m
( 189.96 ft)
|
23.2 m
( 76.12 ft)
|
11.6 m
( 38.06 ft)
|
5.8 m
( 19.03 ft)
|
|
*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
|
|
|
Intelligence
|
|
IVS (Perimeter Protection)
|
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human);
|
|
SMD
|
SMD Plus
|
|
Smart Search
|
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
|
|
Video
|
|
Video Compression
|
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
|
|
Smart Codec
|
Smart H.265+; Smart H.264+
|
|
Video Frame Rate
|
Main stream: 2688 × 1520@(1–20 fps)/2560 × 1440@(1–25/30 fps)
sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Streaming Capability
|
2 streams
|
|
Resolution
|
4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
|
|
Bit Rate Control
|
VBR;CBR
|
|
Video Bit Rate
|
H.264: 32 kbps–6144 kbps;
H.265: 12 kbps–6144 kbps
|
|
Day/Night
|
Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120 dB
|
|
White Balance
|
Auto; natural; street lamp; outdoor; manual; regional custom
|
|
Gain Control
|
Auto/Manual
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Smart Illumination
|
Yes
|
|
Defog
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (Support 90°/270° with 2688 ×1520 resolution and lower)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
LDC
|
Yes
|
|
Audio
|
|
Built-in MIC
|
Yes, built-in Mic
|
|
Audio Compression
|
G.711a; G.711Mu; PCM; G.726
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Network Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration
|
|
Interoperability
|
ONVIF (Profile S & Profile G & Profile T & Profile M); CGI
|
|
User/Host
|
20 (Total bandwidth: 48 M)
|
|
Storage
|
FTP; SFTP; Micro SD card (support max. 256 GB); NAS
|
|
Browser
|
IE; Chrome; Firefox
|
|
Management Software
|
Smart PSS Lite; DSS; DMSS
|
|
Mobile Client
|
iOS;Android
|
|
Security
|
Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade;Session security;Security warning
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
|
|
Power
|
|
Power Supply
|
12 VDC (±30%); PoE (802.3af)
|
|
Power Consumption
|
Basic: 1.4 W (12 VDC); 1.7 W (PoE);
Max.: 5.4 W (12 VDC); 6.3 W (PoE) (H.265+ intelligence on + WDR + illuminator intensity)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Operating Humidity
|
≤95% (RH), non-condensing
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Storage Humidity
|
≤95% (RH), non-condensing
|
|
Protection
|
IP67
|
|
Anti-corrosion Level
|
Basic Protection
*The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection.
|
|
Structure
|
|
Casing Material
|
Metal
|
|
Product Dimensions
|
197.9 mm × 80.2 mm × 76.2 mm (7.79" × 3.16" × 3.00") (L × W × H)
|
|
Net Weight
|
0.56 kg (1.23 lb)
|
|
Gross Weight
|
0.70 kg (1.54 lb)
|
