Dahua NVR 8 Channel Compact 1U 1HDD 8PoE Network Video Recorder , 1xSATA Port MAX16TB , USB , HDMI , VGA , 1XRJ45 Port 10/100Mbs , 8 × PoE ports, 10/100 Mbps , Smart H.265+/H.265 , Resolution: 12MP; 8MP; 5MP; 4MP; 3MP; 2MP; 720p; D1
8 Channel 8PoE Network Video Recorder
Overview
Dahua Lite series NVR is easy to install, cost effective and compatible
with a wide variety of third-party devices, providing a great solution
for small and medium surveillance systems. It is ideal for home safety,
supermarkets, warehouses, educational institutions, and financial
institutions.
Feature(s)
- Smart H.265+/H.265/Smart H.264+/H.264 decoding format
- Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding
- AI by camera: perimeter protection,and SMD Plus
- Connected to the third-party network cameras
- Security baseline 2.1
Specifications
System
- Main Processor : Industrial-grade embedded processor
- Operating System : Embedded Linux
- Operating Interface : Web; Local GUI
AI
- AI by Camera : Perimeter protection; SMD Plus
Perimeter Protection
- Perimeter Performance of AI by Camera (Number of Channels) : 4
SMD Plus
- SMD Plus by Camera : 4-channel SMD Plus (AI by camera), secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change
Audio and Video
- Access Channel : 8 channels
- Network Bandwidth : Access: 80 Mbps; Storage: 80 Mbps; Forward: 60 Mbps
- Resolution : 12MP; 8MP; 5MP; 4MP; 3MP; 2MP; 720p; D1
- Decoding Capability
- 1-channel 12MP@30 fps; 1-channel 8MP@30 fps;
- 2-channel 5MP@30 fps; 3-channel 4MP@30 fps;
- 6-channel 1080p@30 fps
- Video Output 1 × VGA, 1 × HDMI (simultaneous)
- Multi-screen Display 1, 4, 8, 9 views
- Third-party Camera Access : Onvif
Compression Standard
- Video Compression : Smart H.265; H.265; Smart H.264; H.264
- Audio Compression : PCM; G711A; G711U; G726
Network
- Network Protocol : HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter;
- DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); P2P
- Mobile Phone Access : Android; iOS
- Interoperability : ONVIF (profile T/S/G); CGI; SDK
- Browser : Chrome; IE 9 or later; Firefox
Recording Playback
- Multi-channel Playback : Up to 8 channels
- Record Mode : Manual record; alarm record; motion detection record; schedule record
- Storage Method : Local HDD and network
- Backup Method : USB device
- Playback Function
- Play; pause; stop; fast forward; fast backward; rewind; play by frame
- Full screen; backup (video clip/file); partially zom in; audio on/off
Alarm
- General Alarm : Motion detection; privacy masking; video loss; PIR alarm
- Anomaly Alarm : Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; cyber security exception
- Intelligent Alarm : Perimeter protection; SMD Plus
- Alarm Linkage : Recording; snapshot; buzzer; log; preset; email; tour
Port
- Audio Input : 1
- Audio Output : 1
- HDD Interface : 1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment
- temperature
- USB : 1 front USB 2.0 port, 1 rear USB 2.0 port
- HDMI : 1
- VGA : 1
- Network Port : 1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port
- PoE Port : 8 × PoE ports, 10/100 Mbps
General
- Power Supply : 48/53 VDC, 2/1.8 A
- Power Consumption
- Total output of NVR is ≤ 10 W (without HDD)
- Total output power of PoE is 72 W, the maximum output power of asingle port is 25.5 W
- Net Weight : 0.89 kg (1.95 lb)
- Gross Weight : 1.94 kg (4.28 lb)
- Product Dimensions : 260 mm × 232.7 mm × 47.6 mm (10.24" × 9.16" × 1.87") (W × L × H)
- Operating Temperature : –10 °C to +55 °C (14 °F to +131 °F)
- Operating Humidity : 10%–93% (RH)
- Installation : Rack or desktop
Downloads
Additional Information
| Device |
Network Video Recorder |
| Type |
8 Channel | PoE |
Enhance your surveillance system with the Dahua NVR2108HS-8P-S3, a compact 8-channel network video recorder designed for seamless integration and high-definition monitoring. With Smart H.265+ decoding and 8 PoE ports, it delivers exceptional video quality and easy installation, making it perfect for homes, schools, and retail spaces. Enjoy reliable performance with up to 16TB storage and advanced AI features for intelligent alerts and reduced false alarms. Secure your space effortlessly with this efficient and user-friendly NVR.
