System
|
|
Main Processor
|
Embedded Processor
|
|
Operating System
|
Embedded Linux OS
|
|
Button Type
|
Mechanical
|
|
Number of Buttons
|
1
|
|
Interoperability
|
ONVIF; CGI
|
|
Network Protocol
|
IPv4; RTSP; UDP; DNS; P2P; RTP; TCP; SIP
|
|
Basic
|
|
Camera
|
1/2.8" 2 MP CMOS high definition, low illumination/DWDR/ color/IR
|
|
Field of View
|
H: 107°; V: 60°; D: 122°
|
|
Noise Reduction
|
3D NR
|
|
Video Compression
|
H.264; H.265
|
|
Video Resolution
|
Main stream: 720p, WVGA, D1, CIF
Sub stream: 1080p, WVGA, D1, QVGA, CIF
|
|
Video Frame Rate
|
PAL: 25 fps;
NTSC: 30 fps
|
|
Video Bit Rate
|
256 Kbps–8 Mbps
|
|
Light Compensation
|
Auto IR
|
|
Day/Night
|
Auto(ICR)/Color/B/W;Color/B/W
|
|
Audio Compression
|
G.711a; G.711u; PCM
|
|
Audio Input
|
1
|
|
Audio Output
|
Built-in speaker
|
|
Audio Mode
|
Two-way audio
|
|
Audio Enhancement
|
Echo suppression/digital noise reduction
|
|
Audio Bit Rate
|
16 KHz, 16 bit
|
|
Function
|
|
Communication Mode
|
Full digital
|
|
Unlock Mode
|
Card; app; indoor monitor
|
|
Card Type
|
IC card
|
|
Leave Videos
|
Yes (an SD card must be inserted in the VTH)
|
|
Web Configuration
|
Yes
|
|
Performance
|
|
Card Reading Distance
|
0 cm–4.5 cm (0"–1.77")
|
|
Issue Card Locally
|
Yes
|
|
Casing Material
|
PC + Acrylic
|
|
Capacity
|
|
Card Capacity
|
10000
|
|
Port
|
|
RS-485
|
1
|
|
Power Output
|
1 port, 12 V and 200 mA
|
|
Exit Button
|
1
|
|
Door Status Detection
|
1
|
|
Lock Control
|
1 port, normally closed by default
|
|
Network Port
|
1 × 10/100 Mbps network port (8-core white
ribbon cable)
|
|
Alarm
|
|
Tamper Alarm
|
Yes
|
|
General
|
|
Appearance Color
|
Black
|
|
Power Supply
|
12 VDC, 1 A
Standard PoE
|
|
Power Adapter
|
Optional
|
|
Installation
|
Surface Mount
|
|
Certifications
|
CE
|
|
Accessory
|
Included: Alarm power ribbon cable, rain cover, brackets
|
|
Product Dimensions
|
135.1mm × 70.6mm × 34.6mm (5.32" × 2.78" × 1.36")
|
|
Protection
|
IP65 (silicone sealant is needed, see the quick start guide.)
IK04 (for common use)
|
|
Operating Temperature
|
–30 °C to +60 °C (–22 °F to +140°F)
|
|
Operating Humidity
|
10%–90% (RH), non-condensing
|
|
Operating Environment
|
Outdoor
|
|
Operating Altitude
|
Beneath 3000 m (9842.52 ft)
|
|
Power Consumption
|
≤ 1 W (standby), ≤ 5 W (working)
|
|
Gross Weight
|
326 g (0.72 lb)
|
|
Anti-corrosion Level
|
Basic Protection
|
