DHA XVR5108HE-I3/T
SKU: DHA XVR5108HE-I3/T
BRAND: Dahua
R 2,085.53 (inc VAT) R 1,813.50 (ex VAT)
🚚
Delivery time: 2-5 working days for South Africa
✓
In stock - Ready for immediate dispatch
Free shipping for orders over R1,000.00
Dahua 8CH Penta-Brid 5MP Value 1080P Mini 1U 1HDD WizSense DVR, 8-channel AI Coding, HDCVI/AHD/TVI/CVBS & IP, RS485/HDMI/VGA, 2xUSB2.0, 1xRJ45 10/100Mbs, 1xSATA Port Max 16TB, PSU:12VDC2A, 325×257.1x55.0mm, 1.8kg
8CH 5MP Mini 1U 1HDD WizSense Digital Video Recorder
Feature(s)
Dolynk cloud version: DMSS 2.0.30 and above, Dolynk Care 2.50.20 and above
8-channel two-way talk over coaxial cable, enabling seamless communication between camera, client, and recorder
2-channel AcuPick for analog channels, improving target retrieval efficiency
4-channel perimeter protection for analog channels, supporting AI-powered tripwire and intrusion detection
2-channel face recognition for analog channels, supporting face comparison
8-channel SMD Plus for analog channels or 12-channel SMD by camera, providing accurate human and vehicle alarms
8-channel AI Coding, reducing storage and bandwidth usage while preserving target details
Supports HDCVI, AHD, TVI, CVBS, and IP video input
Supports up to 12-channel IP camera input, with up to 6 MP per channel
Incoming bandwidth up to 64 Mbps
Supports access to Wi-Fi cameras, suitable for a wide range of application scenarios
Smart H.265+ and H.265 dual-stream video compression
Specifications
Category
Specification
Main Processor
Industrial-grade processor
Operating System
Embedded Linux
Operating Interface
Web; Local GUI
AcuPick
Supported
AcuPick Performance (1080P)
2 channels
AI Functions
Feature
Specification
Perimeter Protection
4 channels
IVS Rules
10 rules per channel
Face Attributes
6 attributes
Face Detection Performance
2 channels (up to 8 face images/s per channel)
Face Database Capacity
Up to 10 databases, 10,000 images
Face Recognition Performance
2 channels
SMD Plus (Recorder)
8 channels (human & vehicle filtering)
SMD by Camera
12 channels
AI Video Quality Analytics
8 channels (brightness, color cast, defocus, overexposure, contrast, B/W)
Scene Changing
1 channel
Irregular Black Block Masking
1 channel
Audio & Video
Feature
Specification
Analog Camera Input
8 × BNC (HDCVI/AHD/TVI/CVBS autodetect)
Supported Analog Resolutions
Up to 5MP (varies by format: CVI/TVI/AHD)
IP Camera Input
Up to 12 channels
Default IP Channels
4 (expandable to 12)
Bandwidth
Incoming/Recording/Outgoing: 64 Mbps
Dual Stream
Yes
Video Bit Rate
32 kbps – 6144 kbps
Audio Sampling
8 kHz / 16 bit
Audio Bit Rate
64 kbps
Video Output
1 HDMI, 1 VGA
HDMI Resolution
1920×1080, 1280×1024, 1280×720
VGA Resolution
1920×1080, 1280×1024, 1280×720
Multi-screen Display
1/4/8/9 (IP ext. off), 1/4/9/16 (IP ext. on)
Compression & Compatibility
Feature
Specification
Video Compression
AI Coding, Smart H.265+, H.265, Smart H.264+, H.264
Audio Compression
G.711a, G.711u, PCM
Third-Party Camera Support
Panasonic, Sony, Hanwha, Axis, Arecont, ONVIF
ONVIF
24.12 (Profile T, S, G)
Browser Support
Chrome, IE, Safari, Edge, Firefox
Recording & Playback
Feature
Specification
Record Modes
General, alarm, motion detection, intelligent
Playback Channels
1/4/9
Backup Method
USB device, Network
Playback Modes
Instant, general, event, tag, smart
Alarm & Event
Feature
Specification
General Alarm
Motion, local, alarm box, HDCVI, PIR, network
Anomaly Alarm
Disk error, low space, network disconnection, IP conflict
Intelligent Alarm
Face detection/recognition, perimeter, SMD Plus
Alarm Linkage
Record, snapshot, alarm output, audio, buzzer, email
Ports & Storage
Feature
Specification
Audio Input
8-channel RCA / BNC
Audio Output
1-channel RCA
Two-way Talk
Coaxial & network
Alarm Input
8 channels
Alarm Output
3 channels
Disk Interface
1 SATA (up to 16 TB)
USB
2 × USB 2.0
Network Port
1 × RJ-45 (10/100 Mbps)
RS-485
1
General
Feature
Specification
Power Supply
12 VDC, 2 A
Power Consumption
< 7 W (without HDD)
Net Weight
1.21 kg
Gross Weight
1.85 kg
Dimensions (W×D×H)
325.0 × 257.1 × 55.0 mm
Packaging Dimensions
374.0 × 119.0 × 311.0 mm
Operating Temperature
–10 °C to +55 °C
Storage Temperature
–20 °C to +60 °C
Operating Humidity
10%–90% RH
Installation
Desktop
Certifications
CE-LVD, CE-EMC
Downloads
Additional Information
Device
Digital Video Recorder
Enhance your security with the DHA XVR5108HE-I3/T 8CH Penta-Brid DVR, featuring AI coding for efficient storage and advanced face recognition. With support for multiple camera types and seamless two-way audio, this compact recorder ensures reliable surveillance for any environment. Enjoy peace of mind with its intelligent alerts and robust performance, perfect for both home and business security needs.
