• High quality imaging with 2 MP, 1920 × 1080 resolution
• 24/7 color imaging with F1.0 aperture
• Clear imaging against strong back light due to 130 dB true WDR technology
• 3D DNR technology delivers clean and sharp images
• Fixed focal lens, 2.8 mm
• Up to 20 m white light distance for bright night images
• High quality audio with audio over coaxial cable, built-in microphone

Camera

• Image Sensor : 2 MP CMOS
• Max. Resolution : 1920 (H) × 1080 (V)
• Min. Illumination : 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter Time : PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
• Day & Night : 24/7 Color Imaging
• Angle Adjustment
  • Pan: 0 to 350°, tilt: 0 to 75°
  • *DO NOT adjust the angle of the main body or enclosure manually.
• Signal System : PAL/NTSC
• Slow Shutter : Max. 16 times

Lens

• Lens Type : Fixed focal lens, 2.8mm
• Focal Length & FOV : 2.8 mm, horizontal FOV: 106°, vertical FOV: 57°, diagonal FOV: 126°
• Lens Mount : M12

Illuminator

• Supplement Light Type : White Light
• Supplement Light Range : Up to 20 m
• Smart Supplement Light : Yes


• Image Parameters Switch : STD/HIGH-SAT/HIGHLIGHT
• Image Settings : Brightness;Contrast;Mirror;Sharpness;Anti-Banding;Saturation;AGC
• Frame Rate : TVI: 1080P@25 fps/30 fps
• Day/Night Mode : Color
• Wide Dynamic Range (WDR) : ≥130 dB
• Image Enhancement : BLC;HLC;Global;HLS
• Privacy Mask : 4 programmable privacy masks
• Noise Reduction : 3D DNR/2D DNR
• White Balance : Auto/Manual
• White Light : Auto/Off

Interface

• Video Output : 1 HD analog output
• Alarm : Solid Light Alarm (White Light)
• Built-in Microphone : Yes

Event

• Motion Detection : 4 programmable motion areas

General

• Power
  • 12 VDC ± 25%, max. 7.4 W
  • *You are recommended to use one power adapter to supply the power for one camera.
• Material : Plastic
• DimensionØ : 123.7 × 110.8 (4.9" × 4.4")
• Weight : Approx. 290 g (0.6 lb.)
• Operating Condition : -10 °C to 40 °C (14 °F to 104 °F). Humidity 90% or less (non-condensing)
• Communication : HIKVISION-C
• Language : English

1. Datasheet - HKV DS-2CE70DF3T-PTS (2.8MM)
