• Standard PoE
• 2 MP HD camera
• Noise suppression and echo cancellation
• Low illumination
• Access control functions
• Configuration remotely via Web

• Standard PoE
• 2 MP HD camera
• Noise suppression and echo cancellation
• Low illumination
• Access control functions
• Configuration remotely via Web

System parameters

• Operation system : Embedded Linux operation system
• Flash : 32 M
• RAM : 256 M

Video Parameters

• Camera : 2MP HD camera
• Night vision : Low illumination IR supplement mode:3 m
• WDR : True WDR
• Field of view : Horizontal: 88° Vertical: 45° Diagonal: 106°

Video compression standard : H.264

• Stream:

  • Main stream: 1080p@30fps, 720p@30fps
  • Sub stream: D1
• Resolution:

  • Main stream: 1920 × 1080p, 720p
  • Sub stream: 704 × 576
• Motion detection : Support
• Anti-flicker frequency : 50 Hz, 60 Hz

Audio parameters

• Audio intercom : Two-way audio communication
• Audio input : Built-in omnidirectional microphone
• Audio output : Built-in loudspeaker
• Audio compression standard : G.711 U
• Audio compression Rate : 64 Kbps
• Audio quality : Noise suppression and echo cancellation

Network parameters

• Wired network : PoE, 10/100 Mbps self-adapted
• Network protocol : TCP/IP, RSTP

Access control parameters

• Swiping card frequency : /
• Relay : 1

Interfaces

• Debugging port : 1
• Alarm input : 1
• Grounding : 1

General

• Protection level : IP65, IK09
• Button : 1
• Power supply : IEEE802.3af, standard PoE 12 VDC
• Power consumption : < 10 W
• Working temperature : -30°C to +50° C(-22° F to 122° F)
• Working humidity : 10% to 90%
• Heat module : Support
• Installation : Surface mounting
