Hikvision Wireless 180° Panoramic Detector 868MHZ, Tri-X Wireless, Two-Way RF Wireless, Detection Range:15m, Battery Type:CR123A×5, 20000lux, Active IR Anti-Masking, Pet Immunity:Upto 40 kg, Mounting Height:0.8~1.2m, IP65, AES-128 Encryption
Wireless 180° Panoramic Detector
Overview
Wireless 180° Panoramic Detector is a two-way wireless
outdoor quad PIR detector with 180° lens coverage. This
device is designed to protect the outdoor areas of your
property and especially suitable for large free space
applications.
Features
- 180° panoramic coverage
- Active IR anti-masking
- IP65 weather resistance for outdoor application
- Multiple enrollment methods and easy installation
- Frequency hopping against jamming for reliable transmission
Specifications
Detection Performance
- Detection Method : Passive infrared
- Sensor Model : SFG323-711
- Detection Range : 15 m
- Detection Angle : 180°
- Detection Zones : 40
- Detectable Speed : 0.3 to 2m/s
- Sensitivity : Auto,Low
- White Light Filter : 20000lux
- Pet Immunity : Up to 40 kg (cm height)
- Digital Temperature Compensation : Support
- Anti-masking : Support
- Adaptable Coverage : Pattern mask included
Feature
- Digital Processing : Support
- Sealed Optics : Support
- Tamper Protection : Front, rear
- Environment Temperature Indicator : Support
- Signal Strength Indicator : Support
Interface
- Power Switch : Power up enrolling
- LED Indicator Blue(alarm), green+orange(mask)
Transmission
- Transmission Technology : Tri-X Wireless
- Transmission Method : Two-Way RF wireless
- Transmission Frequency : 868 MHz
- Transmission Security : AES-128 encryption
- Transmission Range(Free Space) : 1.6 km
- Frequency Hopping : Support
- Enrolling Method : Power up, remote ID, QR code
Electrical Characteristics
- Standard Battery Life : Up to 5 years (standby time) (The battery working time can be significantly reduced at low temperatures)
- Power Supply : Battery powered
- Battery Type : CR123A × 5
- Typical Voltage : 3V
General
- Operation Temperature : -25°C to 60°C (-13°F to 140°F)
- Storage Temperature : -25°C to 60°C (-13°F to 140°F)
- Operation Humidity : 10% to 90%
- IP Rate : IP65
- Dimension(WxHxD) : 75 mm × 202 mm × 73 mm
- Weight : 512.5 g
- Mounting Height : 0.8 m to 1.2 m
- Mounting Method : Wall
- Application Scenario : Outdoor
