Microwave Ceiling Mount Motion Sensor 360°, 16M Detection Distance, Identify Day & Night Automatically, 3-2000 Lux Adjustable, Time Delay and Ambient Light Adjustment, 220~240VAC, IP20
Microwave Ceiling Mount Motion Sensor
Overview
The MS363 automatically turns on lights or any electrical device within the sensors rated load. It detects through obstacles like doors, glass panels, and thin walls, with a 360° detection range when mounted on a ceiling and adjustable settings for time, Lux level and sensitivity. The MS363 can simply be integrated into new or existing installations, it excels in detecting subtle movements over large areas compared to PIR sensors. Its IP20 rating is suitable for indoor installation. Installation must be done by a qualified electrician.
Application:
- Ideal for home use and in educational and commercial properties
- Detects through doors, glass panes or thin walls
Features
- Detects even the slightest motion
- 3 – 2000 LUX (Adjustable)
- 360° Detection Area
- 16m Detection Distance
- Automatically turns on lights when motion and body heat is detected
- Time-delay and ambient light adjustment
- Identify day and night automatically
- Rated Load
- 1200W (Incandescent Lamps)
- 300W (LED / CFL)
- IP20 Rating - Indoor Installations
Specifications
|
Function
|
Range
|
|
Detection Area
|
360°
|
|
Detection Distance
|
2m - 16m (Adjustable) <24°C
|
|
Detection Motion Speed
|
0.6 to 1.5m/s
|
|
HF System
|
5.8GHz CW Radar, ISM Band
|
|
Ambient Light
|
<3 to 2000 Lux (Adjustable)
|
|
Installation Height
|
1.5m – 3.5m
|
|
Voltage
|
220 to 240V AC
|
|
Power Frequency
|
50/60Hz
|
|
Rated Load
Incandescent
LED / CFL
|
1200W
300W
|
|
Time Delay
|
10 sec (±3 sec) to 12 min (±1 min)
|
|
Power Consumption
|
<0.9W
|
|
Mounting
|
Ceiling Mount
|
|
Working Temperature
|
-20°C to 40°C
|
|
Working Humidity
|
<93% RH
|
|
IP Rating
|
IP20 (Indoor installation)
|
|
Standards
|
IEC 60669-1 / 60669-2-1
AS/NZS 60669.1 / 60669.2.1
|
Downloads
Additional Information
| Device |
Sensor |
| Type |
Microwave | Ceiling Mount | Motion |
Enhance your indoor lighting with the MAJ MS363 Microwave Ceiling Mount Motion Sensor. With a 360° detection range and 16m distance, it automatically activates lights upon detecting motion, even through obstacles. Adjustable sensitivity and light levels ensure optimal performance, making it perfect for homes, schools, and businesses. Enjoy effortless energy savings and improved safety with this advanced motion sensor.
