TP-LINK AX3000 Wall Plate WiFi 6 Access Point, Speed Rate:2.4GHz@574Mbps, 5GHz@2402Mbps, 2xGigabit LAN Ports, Antennas:2.4GHz:2x3dBi, 5GHz:2x5dBi, Omada App, 802.3af PoE, EU:11.5W, HTTP/HTTPS, Email Alerts, 86x86x42.2mm
AX3000 Wall Plate WiFi 6 Access Point
Specifications
| HARDWARE FEATURES |
| Interface |
• Uplink: 1× 10/100/1000 Mbps Ethernet Port
• Downlink: 1× 10/100/1000 Mbps Ethernet Port |
| Physical Security Lock |
No |
| Button |
Reset, LED |
| Power Supply |
802.3af/at PoE |
| Power Consumption |
EU: 11.5 W |
| Dimensions |
86 × 86 × 42.6 mm (3.4 × 3.4 × 1.7 in) |
| Antenna |
2 Dual-Band Antennas
• 2.4 GHz: 2× 3 dBi
• 5 GHz: 2× 5 dBi |
| Mounting |
Wall Plate Mounting (Kits included) |
| WIRELESS FEATURES |
| Maximum Number of Wireless Clients |
100+** |
| Wireless Standards |
IEEE 802.11ax/ac/n/g/b/a |
| Frequency |
2.4 GHz and 5 GHz |
| Signal Rate |
• 5 GHz: Up to 2402 Mbps
• 2.4 GHz: Up to 574 Mbps |
| Wireless Functions |
• 16 SSIDs (Up to 8 SSIDs on each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• Seamless Roaming§
• Beamforming
• Rate Limit
• Load Balance
• Airtime Fairness
• Band Steering
• Reboot Schedule
• Wireless Schedule
• RADIUS Accounting
• MAC Authentication
• Wireless Statistics
• Static IP/Dynamic IP |
| Wireless Security |
• Captive Portal Authentication§
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Transmission Power |
• CE:
<20 dBm (2.4GHz, EIRP)
<22 dBm (5GHz band1 & 2, EIRP)
<22 dBm (5GHz band3, EIRP) |
| MANAGEMENT |
| Omada App |
Yes |
| Centralized Management |
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Omada Cloud-Based Controller |
| Cloud Access |
Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller. |
| Email Alerts |
Yes |
| LED ON/OFF Control |
Yes |
| Management MAC Access Control |
Yes |
| SNMP |
v1, v2c, v3 |
| System Logging Local/Remote Syslog |
Local/Remote Syslog |
| SSH |
Yes |
| Web-based Management |
HTTP/HTTPS |
| L3 Management |
Yes |
| Multi-site Management |
Yes |
| Management VLAN |
Yes |
| Zero-Touch Provisioning |
Yes. Requiring the use of Omada Cloud-Based Controller. |
| OTHERS |
| Certification |
CE, RoHS |
| Package Contents |
• AX3000 Wall Plate WiFi 6 Access Point EAP650-Wall
• Installation Guide
• Mounting Kits |
| System Requirements |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux |
| Environment |
• Operating Temperature: 0–40 ℃ (32–104 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing |
Downloads
Additional Information
| Device |
Access Point |
| Type |
AX3000 | Wall Plate | WiFi 6 |
Enhance your home or office with the TP-LINK EAP650 Wall Plate WiFi 6 Access Point, delivering lightning-fast speeds of up to 2402 Mbps. Its sleek design fits seamlessly into any environment while providing robust coverage for over 100 devices. Experience reliable connectivity and easy management through the Omada App, making it the perfect solution for your networking needs. Upgrade your WiFi experience today!
