| Camera |
| Image Sensor |
1 / 2.8" CMOS |
| Image Size |
1920 × 1080 |
| Electronic Shutter |
1 /3s ~ 1 / 100000 s |
| Iris Type |
Fixed Iris |
| Min. Illumination |
0.0035 lux@F1.2,AGC ON; 0 lux with IR |
| 0.013 lux@F2.0,AGC ON; 0 lux with IR |
| Lens |
2.8 mm @F2.0, (fixed lens), horizontal field of view: 107° |
| Lens Mount |
M12 |
| Wide Dynamic Range |
Digital WDR |
| BLC |
Yes |
| HLC |
Yes |
| Digital NR |
Yes |
| Angle Adjustment |
Pan: 0°~360°; Tilt:0°~90°; Rotation: 0°~360° |
| Image |
| Video Compression |
Main Stream: H.265 / H.264 |
| Sub stream: H.265 / H.264 / MJPEG |
| H.265 Compression Standard |
Main Profile@Leve4.1 High Tier |
| Resolution |
1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240 |
| Main Stream |
60Hz : 1080P( 1 ~ 30fps ) / 720P( 1 ~ 30fps ) |
| 50Hz : 1080P( 1 ~ 25fps ) / 720P( 1 ~ 25fps ) |
| Sub Stream |
60Hz : D1/CIF/480x240 (1~30fps); 50HZ: D1/CIF/480x240 (1~25fps) |
| Bit Rate |
128 Kbps ~ 4 Mbps |
| Bit Rate Type |
VBR / CBR |
| Audio Compression |
G711A / U |
| Image Settings |
ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Defog, Sharpen, NR,etc. adjustable through client software or web browser |
| ROI |
Each ROI to be configured separately |
| Interfaces |
| Network |
RJ 45 |
| Audio |
1CH audio input |
| Storage |
Built-in micro SD card slot; up to 256GB |
| Hardware Reset |
Yes |
| Functions |
| Remote Monitoring |
Web browser /TVT NVR/NVMS2.X/Mobile APP |
| Online Connection |
Support simultaneous monitoring for up to 3 users; Support multi-stream real time transmission |
| Network Protocol |
UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, 802.1x, FTP UPnP, HTTPs, HTTP, QoS |
| Interface Protocol |
ONVIF |
| Storage |
Network remote storage; micro SD card storage |
| Smart Alarm |
Motion detection, SD card full, SD card error |
| |
Video blur detection, line crossing detection and region intrusion detection |
| Intelligent Analytics |
| General Function |
Watermark, IP address filtering, video mask, heartbeat, illegal login lock |
| PoE |
Yes |
| IR Distance |
30 ~50 m |
| Ingress Protection |
IP67 |
| Others |
| Power Supply |
DC12V PoE |
| Power Consumption |
< 7.5W |
| Operating Environment |
- 30 °C ~ 60 °C (-22°F~140°F) |
| Humidity: less than 95 % (non-condensing) |
| Dimensions ( mm ) |
217.7 × 80.5 × 80.5 |
| Weight ( net ) |
Approx. 0.66KG |
| Installation |
Ceiling mounting; Wall mounting |
