UPC1187V

• Device Type: Monolithic Audio Power Amplifier
• Package Type: ZIP-15 (15-Pin Zig-Zag In-Line Package)

General Features

• Single-channel audio power amplifier
• Designed for consumer audio equipment
• Built-in thermal protection
• Built-in short-circuit protection
• Minimal external components required
• Suitable for low- to medium-power audio applications

Electrical Characteristics

• Supply Voltage Range:
  • 9 V to 18 V DC
• Recommended Operating Voltage:
  • 12 V to 15 V DC
• Quiescent Current:
  • Low-power operation
• Output Configuration:
  • Single-ended audio power output

Audio Performance

• Output Power:
  • Up to approximately 5 W
  • Depends on supply voltage, load impedance, and heatsinking
• Frequency Response:
  • Designed for full audio-band amplification
• Low Distortion Operation
• High Signal Fidelity

Package Information

• Package: ZIP-15
• Pin Count: 15 Pins
• Mounting Style: Through-Hole
• Integrated Heatsink Tab for mounting to a heatsink

Protection Features

• Thermal shutdown protection
• Output short-circuit protection
• Safe operating area protection

Typical Applications

• Television audio stages
• Portable audio systems
• Radio receivers
• Small stereo systems
• Consumer electronic products
• Active speaker systems
