• Product Family: Sensor / Actuator Connectors
• Product Sub Family: M12 Standard
• Brand: Lumberg Automation
• Connector Type: Cordset, single ended
• Type of Contact / Gender: Female
• Connector Design: Straight
• Number of Pins: 4
• Coding: A
• Shielding: Shielded
• Attachment Type: Coupling Nut
• Rated Voltage: 60 V
• Rated Impulse Voltage: 1.5 kV
• Operating Voltage: 50 V AC / 60 V DC
• Rated Current: 4 A
• Contact Resistance: ≤ 10 mOhm
• Insulation Resistance: ˃ 10^9 Ohm
• Mating Cycles: ≤ 100
• Ambient Temperature (Operation): - 40 °C - + 90 °C
• Protection Degree / IP Rating: IP65, IP67, IP69K
• Design Standard: IEC 61076-2-101
• Pollution Degree: 3 acc. to DIN EN 60664-1 (VDE 0110-1)
• Overvoltage Category: III acc. to DIN EN 60664-1 (VDE 0110-1)

Materials

• Contact Base Material: CuSn
• Contact Plating: Cu/Au
• Contact Bearer Material: PA
• Contact Bearer Color: Black
• Flammability Class (Contact Bearer): UL 94 V-0
• Molded Body Material: TPU
• Molded Body Color: Orange
• Flammability Class (Molded Body): UL 94 HB
• Attachment Material: CuZn
• Attachment Plating: Nickel-plated
• Shielding Material: CuZn, tin-plated
• O-Ring Material: FKM, green

Additional Technical Data

• Fastening Torque (Attachment): M 12x1: (50-60) Ncm, hand-tight

Cable Data

• Cable Number: 288
• Number of Wires: 4
• Minimal Bending Radius (Fixed Inst): ˃ 5 x D
• Minimal Bending Radius (Flexible Inst): ˃ 10 x D
• Cycles (Bending): ˃ 5 M
• Cycles (Torsion): ˃ 1 M @ ± 180 °/1 m
• Conductor material: Cu
• Cable Jacket Material: PUR
• Cable Jacket Color: black
• Cable Diameter D: ø 5.50 ± 0.20 mm
• Wire Insulation Material: PP
• Insulated Wire Diameter: ø 1.30 mm
• Overall Shield (Cable): Mesh wire
• Ambient Temperature (Fixed Installation): - 50 °C - + 80 °C
• Ambient Temperature (Flex Installation): - 25 °C - + 80 °C
• Ambient Temperature (Drag Chain Inst): - 25 °C - + 60 °C
• UL Cable Type: AWM: 20549

1. Datasheet - RKTS4-288/10M
