General Data

• Housing Material: PBT + ASA
• Housing Color: Black
• Protection Degree / IP Rating**: IP67
• Potted: No
• Dimensions (W x H x D): 60 mm x 40 mm x 243 mm
• Weight: 390 g
• Ambient Temperature (Operation)*: -10 °C to 60 °C
• Vibration Resistance: 10 g / 5 -500 Hz
• Shock Resistance: 50 g / 11ms
• Contact Base Material: M12, B-coded, CuSn, Gold-plated | 7/8" CuZn, Gold-plated
• Contact Bearer Material: PA / TPU
• O-Ring Material: FKM
• Mounting: 2 hole screw mounting. Use standard M4 x 25 / 30 screws with toothed lock washer (as per DIN 125) and self-locking nuts.
• Fastening Torque (Fixing Screw): M4: 1 Nm
• Fastening Torque (Ground Connection (FE)): M4: 1 Nm
• Fastening Torque (Bus Connection): M12: 0.5 Nm
• Fastening Torque (Power Connection): 7/8": 1.5 Nm
• Fastening Torque (I/O Connection): M12: 0.5 Nm
• Included in Delivery: Attachable Labels: 15x, Sealing Caps: 4x M12

PROFIBUS

• Connection: M12, 5-poles, B-coded
• Number of Connections: 2
• Transmission Rate: 9.6 kbps ... 12 Mbps
• Transmission Rate Adjustment: Automatically with start of the communication
• Addressing via Rotary Address Switches: 1 ...99 dec
• Addressing via PROFIBUS: 1 ...125 dec
• ID Number: 09CA hex

Power Supply

• Connection Module Supply Voltage: 7/8" Power, 5-poles
• Number of Connections: 2
• Current Carrying Capacity of Connector: max. 9 A
• Module Supply Voltage (Nominal): 24 V DC (SELV/PELV)
• Module Supply Voltage (Range): 19 V DC to 30 V DC
• Current Consumption (typ.): 70 mA (at 24 V DC)
• Reverse Polarity Protection: Yes
• Status Indicator (System Supply): LED green
• Diagnostic Indicator: No
• Connection Sensor Supply Voltage: via Module Supply Connection
• Current Carrying Capacity of Connector: max. 9 A
• Sensor Supply Voltage (Nominal): 24 V DC (SELV/PELV)
• Sensor Supply Voltage (Range): 19 V DC to 30 V DC
• Reverse Polarity Protection: Yes
• Status Indicator (Sensor Supply): LED green
• Diagnostic Indicator: No

1. Datasheet - 0970 PSL 701
