ABS Enclosure 147.24 x 89 x 25 mm Soft Side Black
Features
- Ergonomically designed for hand-held comfort
- Choice of five sizes and six color combinations
- Choice of two versions in the three larger sizes (ie...with or without battery door & compartment)
- Molded in general purpose ABS plastic with an overmold, soft plastic grip
- Top cover is recessed for membrane display or keypad
- P.C. board standoffs are molded into case (see drawings or photos for more details)
- Includes removable front panel (for easy modifications) and assembly hardware (except for smallest 1553A units)
- Battery door & compartment version includes 4 battery clips (for 2 - AA batteries) and a 9 volt (PP3) battery clip
- Gray 1553 series enclosures include nickel plated screws. All other color use black screws. Refer to product datasheets for correct part numbers
- For similar enclosures designed for water-tight applications, try series 1553W
Specifications
Product Type |
Soft Sided Hand-Held Enclosure |
Series |
1553 |
Body Material |
ABS Plastic |
External Dimensions |
147.24 x 89 x 25 mm |
External Length |
147.24 mm |
External Width |
89 mm |
External Height |
25 mm |
Internal Dimensions |
140.24 x 65.95 x 19.5 mm |
Internal Length |
140.24 mm |
Internal Width |
65.95 mm |
Internal Height |
19.5 mm |
Colour |
Black |
IP Rating |
IP54 |
Lid Colour |
Grey |
Flame Rating |
UL94-HB |
