BRAND: Hammond

Diecast Aluminium Unpainted 120 x 94 x 58.5mm Watertight Enclosure

Diecast Aluminium Unpainted Enclosure


  • Rugged, Diecast alluminium alloy (tough yet easy to machine), electronic instrument enclosure.
  • Lap joint construction with a factory poured silicone rubber gasket around the perimeter of the lid provides protection against access of dust and water.
  • Silicone rubber gasket remains flexible from -62 to +232ºC (-80 to +450 ºF).
  • Flanged lid allows for easy mounting to walls or shelves & provides high security (as lid screws are hidden against wall or shelf).
  • These enclosures share the same body and features as our regular type 1590 enclosure except the lid is extended and four countersunk holes are cast into the flanges.
  • Four stainless steel machine screws secure lid - into factory tapped holes.
  • Screws use neoprene "O" rings (included).
  • Designed to meet IP65.
  • Low side wall draft angle (2 degrees or less) for easy P.C. board mounting.

Additional Information

Device Enclosure
Type Diecast | Aluminium | Unpainted | Watertight
Body Material Diecast Aluminium
Dimensions 120 x 94 x 58.5mm
Base Colour Unpainted
