1598BBSGYPBK

SKU: 1598BBSGYPBK

BRAND: Hammond


Instrument Enclosure • Polystyrene Plastic • with Aluminium End Panels • 179 x 154.5 x 35 mm • Grey enclosure Black Panel

Features

  • Desktop electronic instrument enclosure, ideally suited for mounting printed circuit boards
  • Designed to meet IP54
  • Two sets of vertical 1.5 mm (0.062") P.C. Board guides are molded into case halves front and rear
  • Front and rear panels are 1.6 mm (0.064") brushed aluminium with protective paper on one side
  • Enclosure halves are secured with m3 x 0.5" x 10 mm (0.39") phillips machine screws threaded into tapped integral brass bushings. Perfect for applications with repetitive assembly and disassembly are required
  • Integral horizontal P.C. Card mounts on eurocard centers

Specifications

Product Type Instrument Enclosure
Series 1598
Body Material Polystyrene Plastic
External Dimensions 179 x 154.5 x 35 mm
External Length 179 mm
External Width 154.5 mm
External Height 35 mm
Internal Dimensions 168.8 x 145.21 x 30 mm
Internal Length 168.8 mm
Internal Width 145.21 mm
Internal Height 30 mm
Colour Grey
IP Rating IP54
Lid Colour Black
Flame Rating UL94-HB
