1599ESGY

SKU: 1599ESGY

BRAND: Hammond


Hand Held Enclosure • Polystyrene Plastic • 170x85x34mm • Grey

Hand Held Enclosure

Feature(s)

  • Attractively styled and ergonomically designed for use as a “hand-held” instrument enclosure.
  • Standard version is molded from flame retardant ABS plastic (rated UL94V-0) and is assembled with machine screws into integral brass bushings.
  • Economy version is molded from economical plastic (not flame retardant) and is assembled with self-tapping screws into plastic posts.
  • Recessed top for membrane display or pad.
  • Lap joint construction provides protection against access of dust and splashing water.
  • Extra deep top and ultra shallow base are specifically designed to enhance the aesthetics of the enclosure and provide the user with flexibility and assembly efficiency.
  • Designed to meet IP54.

Specifications

Size L x W x H 6.7 in x 3.35 in x 1.33 in
(170 mm x 85 mm x 34 mm)
Shipping Weight 0.28 lbs (0.13 kg)
UNSPSC 39121301
UPC 623980566962
Packaging Type shrink wrap
Material ABS Plastic
Color Light Gray
Flame Rating UL94 HB
IP Rating IP54
Product Category Enclosures
Type Hand-held, general purpose
Max. P.C. Board Length (mm) 72
Max. P.C. Board Width (mm) 162.5

Downloads

Additional Information

Sub Group Hand Held
Device Enclosure
Type Hand Held
