2SA766

Name: 2SA766 - Communica [Part No: 2SA766]
Brand: Communica
SKU: 2SA766
Price: 14.35 ZAR
Availability: InStock

SKU: 2SA766

BRAND: Communica

R 16.50_{(inc VAT)}
R 14.35_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Semiconductors

Type: Transistors

Category: PNP Silicon Epitaxial Planar Transistor

P 150V 400MA

Specifications

Case	TO66
Type	Transistor Silicon PNP
Manufacturer	Matsushita Electronics
Vbr CBO	150
Vbr CEO	150
Max. PD (W)	20
Derate (Amb) (W/°C)	160m
Max. hFE	150
Min hFE	30
Ic Max. (A)	1.2
@Ic (test) (A)	100m
Icbo Max. @Vcb Max. (A)	30u
Polarity	PNP
Oper. Temp (°C) Max.	140
@VCE (V)	5.0
Pinout Equivalence Number	3-14
Surface Mounted Yes/No	NO
Maximum Collector Power Dissipation (Pc)	20 W
Maximum Collector-Base Voltage \|Vcb\|	150 V
Maximum Emitter-Base Voltage \|Veb\|	5 V
Maximum Collector Current \|Ic max\|	1.2 A
Max. Operating Junction Temperature (Tj)	150 °C
Transition Frequency (ft):	15 MHz
Forward Current Transfer Ratio (hFE), MIN	30

Additional Information

Device

Transistor

Upgrade your electronics with the 2SA766 transistor from Matsushita Electronics. This high-performance PNP silicon transistor offers reliable operation at 150V and 1.2A, ensuring optimal efficiency and durability in your circuits. Ideal for various applications, its robust design supports high power dissipation and a wide operating temperature range. Enhance your projects with this essential component today!
