4061 DC48V MOD

SKU: 4061 DC48V MOD

BRAND: Song Chuan


Medium - Hi Power Relay • Form 1C • VCoil= 48V DC • IMax Switching= 16A • RCoil= 3.3kΩ • PCB • Vertical Case

Overview

Features

Specification

  • 8mm Creepage Distance
Model 4061 DC48V MOD
Contact Form Form 1C
Size Category Std Size
Size 29x14x26mm
Termination PCB
Coil Rated Voltage 48V
AC/DC Voltage DC
Max. Switching Current 16A
Electrical Rating 16A/30VDC/250VAC
Coil Power 700mW Power
Coil Resistance 3.3kΩ
Isolation Voltage 4KV
Approvals UL/CSA/TUV
Contact Material Ag
No. of Pins 8 Pin(s)
No. of Poles 1 Pole(s)
