Capacitor Electrolytic Radial Low Impedance 6,3X11 290MA Hitano
Specifications
- Series: WLR
- Product Type: Aluminum Electrolytic Capacitor
- Capacitance: 47 µF
- Rated Voltage: 50 VDC
- Capacitance Tolerance: ±20%
- Mounting Type: Through Hole
- Lead Style: Radial Leads
- Package Size: 6.3 mm (Diameter) × 11 mm (Height)
- Polarity: Polarized
- Impedance: Low Impedance
- Ripple Current: 290 mA (RMS)
- Operating Temperature Range: -40°C to +105°C
- Maximum Operating Temperature: 105°C
- Load Life: Typically 2,000 hours at 105°C
- Leakage Current: Low leakage current
- Applications: Switching power supplies, DC-DC converters, voltage regulation circuits, industrial electronics, telecommunications equipment, LED drivers, and general-purpose filtering
- RoHS Compliance: Yes
- Features: Low impedance design, high ripple current capability, compact radial package, 105°C endurance, long operational life, and reliable performance in high-frequency power supply applications.
Additional Information
| Device |
Capacitor Electrolytic Radial Low Impedance |
| Type |
Electrolytic |
| Highlights |
Capacitor | Electrolytic | Radial | Low | Impedance |
| Dielectric |
Electrolyte |
| Capacitance |
47µF |
| Tolerance |
±20% |
| Rated Voltage |
50V |
| Termination |
Radial |
| Size |
5x11x2mm |
| Lead Spacing |
2mm |
| Diameter |
5mm |
| Height |
11mm |
| Packaging |
Mini |
Enhance your electronic projects with the 47UF 50VR WLR aluminum electrolytic capacitor. Designed for low impedance and high ripple current, this compact 47µF capacitor ensures reliable performance in power supplies and DC-DC converters. With a robust operating temperature range and long lifespan, it’s the perfect choice for reliable voltage regulation and filtering in industrial and telecommunications applications.
