5SY6213-7

Name: 5SY6213-7 - Communica [Part No: 5SY6213-7]
Brand: Sentron
SKU: 5SY6213-7
Price: 823.35 ZAR
Availability: OutOfStock

SKU: 5SY6213-7

BRAND: Sentron

Sold Out
R 946.85_{(inc VAT)}
R 823.35_{(ex VAT)}

Collections: Circuit Protection

Type: Circuit Breakers

Category: 2 Pole Circuit Breakers

Miniature Circuit Breaker 400 V 6kA, 2-Pole, C,13 A, D=70 mm

Miniature Circuit Breaker

Specifications

Product Type: Miniature Circuit Breaker (MCB)
Number of Poles: 2-Pole
Rated Current: 13 A
Tripping Characteristic: C Curve
Rated Operational Voltage:
- 230/400 V AC
- Up to 72 V DC
Frequency: 50/60 Hz
Breaking Capacity:
- 6 kA (EN 60898-1)
- 15 kA (IEC 60947-2)
Rated Insulation Voltage (Ui): 440 V
Overvoltage Category: III
Pollution Degree: 3
Energy Limiting Class: 3
Mechanical Endurance: 10,000 operating cycles
Electrical Endurance: 10,000 operating cycles
Mounting: 35 mm DIN Rail
Terminal Type: Screw terminals
Degree of Protection: IP20 (with connected conductors)
Width: 2 modules (36 mm)
Installation Depth: 70 mm
Operating Temperature: -25°C to +55°C
Storage Temperature: -40°C to +75°C
Standards:
- IEC/EN 60898-1
- IEC 60947-2
Typical Applications:
- Residential distribution boards
- Commercial electrical installations
- Industrial control panels
- Lighting circuits
- Socket outlet circuits
- General-purpose circuit protection

Downloads

Datasheet

Additional Information

Device	Circuit Breaker
Type	Miniature \| Circuit \| Breaker \| 400 \| V \| 6kA

Ensure optimal safety and reliability with the 5SY6213-7 Miniature Circuit Breaker. Designed for 400 V systems, this 2-pole, 13 A breaker offers robust protection with a breaking capacity of 6 kA, making it ideal for residential and commercial applications. Its compact design fits perfectly on a 35 mm DIN rail, providing dependable performance in any environment.
