6EP1334-3BA10
SKU: 6EP1334-3BA10
BRAND: Siemens
R 6,731.81 (inc VAT) R 5,853.75 (ex VAT)
🚚
Delivery time: 2-5 working days for South Africa
✓
In stock - Ready for immediate dispatch
Free shipping for orders over R1,000.00
SITOP PSU200M 10 A Stabilized Power Supply Input: 120/230-500 V AC Output: DC 24 V/10 A (6EP1334-3BA00)
SITOP PSU200M 10 A Stabilized Power Supply
Specifications
Manufacturer: Siemens
Product series: SITOP PSU200M
Product type: Industrial DIN-rail switched-mode power supply
Input voltage (AC): 120–230 V AC / 230–500 V AC (wide range)
Input voltage range: 85–264 V AC / 176–550 V AC
Frequency: 50/60 Hz (47–63 Hz range)
Output voltage: 24 V DC
Output voltage adjustment: 24 – 28.8 V DC
Output current: 10 A
Output power: 240 W
Efficiency: approx. 91%
Ripple & noise: ≤ 50 mV
Hold-up time: approx. 25 ms (typical higher at 230 V)
Inrush current: max. ~35 A
Protection features:
Short-circuit protection (constant current / shutdown)
Overload protection
Overvoltage protection
Parallel operation: supported (for increased load capacity)
Status indication: LED indicators + relay contact signal output
Mounting: DIN rail (EN 60715)
Connection type: Screw terminals
Protection class: IP20
Operating temperature: 0 °C to +60/70 °C (with derating above 60 °C)
Dimensions (W × H × D): 70 × 125 × 121 mm
Weight: approx. 0.8–0.85 kg
Application: Industrial automation, PLC systems, control panels, machine building
Downloads
Additional Information
Device
Power Supply
Type
SITOP | PSU200M | 10 | A | Stabilized | Power Supply
Enhance your operations with the SITOP PSU200M 10 A Stabilized Power Supply. Offering reliable 24V DC output and versatile input options, this power supply ensures optimal performance for your devices, delivering stability and efficiency you can trust. Perfect for industrial applications, it keeps your systems running smoothly.
