6ES7223-1BL22-0XA0

Name: 6ES7223-1BL22-0XA0 - Communica [Part No: 6ES7223-1BL22-0XA0]
Brand: Siemens
SKU: 6ES7223-1BL22-0XA0
Price: 9636 ZAR
Availability: OutOfStock

SKU: 6ES7223-1BL22-0XA0

BRAND: Siemens

Sold Out
R 11,081.40_{(inc VAT)}
R 9,636.00_{(ex VAT)}

Collections: Electromechanical

Type: Industrial Automation

Category: PLC & DCS

SIMATIC S7-200, Digital I/O EM 223, only for S7-22X CPU, 16 DI 24 V DC, Sink/Source, 16DO 24 V DC; 0.75 A/channel,source

SIMATIC S7-200, Digital

Specifications

Product Type: Digital I/O Expansion Module (EM 223)
Compatible CPU: S7-22X CPU Series
Digital Inputs: 16
Digital Outputs: 16
Input Type: 24 V DC Sink/Source
Output Type: 24 V DC Transistor (Source)
Rated Load Voltage: 24 V DC
Supply Voltage Range: 20.4–28.8 V DC
Output Current: 0.75 A per channel
Backplane Bus Current: 160 mA (5 V DC max.)
Power Dissipation: Typical 6 W
Input Voltage:
- Logic "0": 0–5 V DC
- Logic "1": 15–30 V DC
Input Current: Typical 4 mA (Logic "1")
Input Delay (0 → 1): Maximum 4.5 ms
Total Output Current:
- 3 A per output group
- 6 A maximum overall (group dependent)
Short-Circuit Protection: No
Output Voltage:
- Logic "0": Maximum 0.1 V
- Logic "1": Minimum 20 V
Cable Length:
- Shielded: Up to 500 m
- Unshielded: Up to 150 m
Input Isolation: Optocoupler
Output Isolation: Optocoupler
Isolation Voltage: 500 V AC
Connection Method: Plug-in I/O Terminals
Mounting: DIN Rail
Dimensions (W × H × D): 137.5 × 80 × 62 mm
Weight: Approximately 360 g
Certifications:
- CE
- ATEX
- FM
- ABS
- DNV
- LR
- BV
- RMRS
- CCS
Typical Applications:
- PLC digital input/output expansion
- Industrial automation
- Machine control
- Process control
- Factory automation
- Conveyor and production systems

Additional Information

Device	Module
Type	SIMATIC \| S7-200 \| Digital
