7409

SKU: 7409

BRAND: Communica

In Stock
R 10.35_{(inc VAT)}
R 9.00_{(ex VAT)}

Collections: Semiconductors

Type: Logic ICs

Category: Logic Gates

Quad 2-Input AND Gate with Open Collector Outputs

Specifications

Logic Function: Quad 2-input Positive AND
Output Type: Open-Collector (requires external pull-up resistors)
Package: 14-pin DIP (PDIP-14)
Operating Voltage: 4.75V to 5.25V (5V nominal)
Logic Family: 7400 Series TTL (e.g., 74LS09)
Operating Temperature: 0°C to 70°C
Propagation Delay: ~12ns to 20ns
Max Sink Current: 8mA - 16mA

Downloads

sn74als09

Additional Information

Keywords	AND Gate
Device	Logic Gate
