Name: 74180 - Communica [Part No: 74180]
Brand: Communica
SKU: 74180
Price: 3.75 ZAR
Availability: InStock

SKU: 74180

BRAND: Communica

R 4.31_{(inc VAT)}
R 3.75_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over ZAR 1,000.00

Collections: Semiconductors

Type: Memory ICs

Category: Parity Generator | Parity Checker

Generator/Check 9Bit Odd/Even PRT 14PD

Specifications

Logic Family: TTL (74xx series)
Function: 9-bit parity generator/checker
Package: 14-pin DIP (14PD)
Number of Data Inputs: 8 primary data inputs
Cascade/Parity Inputs: 2 (for expansion and checking)
Outputs:
- Odd parity output
- Even parity output
Operating Mode: Parity generation or checking
Supply Voltage (Vcc): 4.75 V – 5.25 V
Absolute Max Vcc: ~7 V
Input Voltage Range: –0.5 V to Vcc
Logic HIGH (VIH): ≥ 2.0 V
Logic LOW (VIL): ≤ 0.8 V
Output HIGH (VOH): ≥ 2.4 V
Output LOW (VOL): ≤ 0.4 V
Propagation Delay: ~15–25 ns typical
Power Dissipation: ~35–60 mW typical
Operating Temperature: 0 °C to 70 °C

Additional Information

Device

Parity Generator | Parity Checker

Enhance your digital circuits with the 74180 9-bit parity generator/checker. This reliable TTL component ensures data integrity through odd/even parity generation and checking. With a compact 14-pin DIP package, it operates seamlessly within 4.75 V to 5.25 V, making it ideal for efficient electronic designs. Boost your project's performance and accuracy today!
