74290

Name: 74290 - Communica [Part No: 74290]
Brand: Communica
SKU: 74290
Price: 19.50 ZAR
Availability: InStock

SKU: 74290

BRAND: Communica

R 22.43_{(inc VAT)}
R 19.50_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over ZAR 1,000.00

Collections: Semiconductors

Type: Logic ICs

Category: IC - Counters

Counter Binary 4-Bit Decade 14PD

Specifications

Logic family: 74xx TTL
Supply voltage (Vcc): 5 V nominal
Operating range: 4.75 – 5.25 V
Input HIGH: ≥ 2.0 V
Input LOW: ≤ 0.8 V
Output current:
- LOW: 8 mA
- HIGH: –0.4 mA
Propagation delay: ~20–35 ns

Feature

4-bit decade (0–9) counter
Binary-coded decimal (BCD) output
Divide-by-2 and divide-by-5 sections
Can be configured as divide-by-10
Asynchronous reset inputs
TTL compatible
Cascade capability for multi-digit counters

Additional Information

Device

Counter

Unlock precision with the 74290 4-Bit Decade Counter, perfect for your digital projects. This TTL-compatible device offers BCD output and customizable division settings, ensuring seamless integration and reliable performance. Enhance your circuitry with its fast propagation delay and asynchronous reset for effortless control. Ideal for both hobbyists and professionals seeking efficiency and versatility in electronic design.
