Name: 7438 - Communica [Part No: 7438]
Brand: Communica
SKU: 7438
Price: 21 ZAR
Availability: InStock

SKU: 7438

BRAND: Communica

R 24.15_{(inc VAT)}
R 21.00_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over ZAR 1,000.00

Collections: Semiconductors

Type: Logic ICs

Category: Logic Gates

Quad 2-Input NAND Buffer with Open Collector Outputs

Specifications

Logic Type: Quad 2-Input NAND Buffer
Outputs: Open-Collector (requires external pull-up resistors)
Package: 14-Pin DIP (Dual In-line Package)
Supply Voltage (
VCCcap V sub cap C cap C end-sub
𝑉𝐶𝐶 ): Typically 4.75V to 5.25V
Low Level Output Current (
IOLcap I sub cap O cap L end-sub
𝐼𝑂𝐿 ): 24mA
Operating Temperature: 0°C to 70°C
Function: Performs the NAND function (
Y=A⋅B¯cap Y equals modified cap A center dot cap B with bar above
𝑌=𝐴⋅𝐵)

Common Applications:

Driving high-capacitance loads
Bus-driving circuits
Wired-AND connections
TTL to MOS interfacing

Additional Information

Keywords	NAND
Device	Buffer

Enhance your electronic projects with the 7438 Quad 2-Input NAND Buffer. Featuring open-collector outputs for high-capacitance loads, this reliable 14-pin DIP device ensures optimal performance in bus-driving circuits and TTL to MOS interfacing. Enjoy seamless operation across a wide temperature range, making it the perfect choice for versatile applications.
