74ABT125BM1

Name: 74ABT125BM1 - Communica [Part No: 74ABT125BM1]
Brand: Communica
SKU: 74ABT125BM1
Price: 17 ZAR
Availability: InStock

SKU: 74ABT125BM1

BRAND: Communica

R 19.55_{(inc VAT)}
R 17.00_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over ZAR 1,000.00

Collections: Semiconductors

Type: Logic ICs

Category: Buffers & Line Drivers

Buffer Quad Gated 3-State SOIC

Specifications

Type: Quad buffer with 3-state outputs
Logic Family: ABT (Advanced BiCMOS TTL)
Number of Buffers: 4
Output Type: 3-state (gated control)
Package: SOIC (Small Outline IC)
Supply Voltage (Vcc): 4.5 – 5.5 V
Input Logic Levels: TTL compatible
Output Drive: High-current CMOS output
Function: Buffers or isolates signals; output enabled/disabled via control pin
Propagation Delay: ~4–6 ns typical (at Vcc=5 V)
Operating Temperature Range: −40 °C to +85 °C (industrial)
Applications:
- Bus driving
- Signal isolation
- Data transfer between circuits

Pin Summary (SOIC-16)

4 buffer pairs with separate enable pins
Pins 1, 4, 10, 13: Output enable control
Pins 2, 5, 11, 14: Inputs
Pins 3, 6, 12, 15: Outputs
Pin 8: GND
Pin 16: VCC

Additional Information

Device

Buffer

Enhance your circuit design with the 74ABT125BM1 Quad Buffer, featuring high-current CMOS outputs and 3-state control for optimal signal isolation and data transfer. With a fast propagation delay of 4-6 ns and a wide operating temperature range of -40°C to 85°C, this reliable buffer is perfect for industrial applications. Experience superior performance and seamless integration in your projects today!
