74LS138M1

Name: 74LS138M1 - Communica [Part No: 74LS138M1]
Brand: Communica
SKU: 74LS138M1
Price: 2.39 ZAR
Availability: InStock

SKU: 74LS138M1

BRAND: Communica

R 2.75_{(inc VAT)}
R 2.39_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over ZAR 1,000.00

Collections: Semiconductors

Type: Logic ICs

Category: Encoder & Decoder ICs

1 of 8 Decoder/Demultiplexer SMD

Specifications

Electrical Characteristics

Supply Voltage (Vcc): 4.75V – 5.25V
Nominal Voltage: 5V
Input HIGH (VIH): ≥ 2.0V
Input LOW (VIL): ≤ 0.8V
Output HIGH (VOH): ≥ 2.7V @ –0.4 mA
Output LOW (VOL): ≤ 0.5V @ 8 mA
Propagation Delay: Typical 15 ns
Power Dissipation: Approx. 20 mW

Functional Characteristics

Address Inputs: 3 (A, B, C)
Outputs: 8 (Y0 – Y7, active LOW)
Enable Inputs:
G1 (Active HIGH)
G2A, G2B (Active LOW)
Logic Function: One of 8 outputs goes LOW depending on the combination of inputs, provided enable inputs are active.

Absolute Maximum Ratings

Vcc: 7V
Input Voltage: –0.5V to 7V
Operating Temperature: 0°C to +70°C
Storage Temperature: –65°C to +150°C

Additional Information

Device

IC

Unlock efficient data routing with the 74LS138M1 decoder/demultiplexer. This high-speed SMD component features a 15 ns propagation delay and supports 3 address inputs for seamless communication. With low power dissipation and robust performance, it's perfect for your electronic projects, ensuring reliability and versatility in any application.
