SKU: 99-3383-00-04

BRAND: Binder



R 313.78 (inc VAT)
R 272.85 (ex VAT)

🚚
Delivery time: 2-5 working days for South Africa
✓
In stock - Ready for immediate dispatch
Free shipping for orders over ZAR 1,000.00

Collections:

Type: Circular Connectors

Category: Circular M8 Industrial Automation Connectors

Circular Connector M8 Cable Male Straight. 4 Pole Sold Terminal. 5mm Max. Cable Entry IP67

M8 Cable Male Straight Circular Connector

Specifications

Connector design Male cable connector
Type standard DIN EN 61076-2-104
Version Connector pin straight
Connector locking system screw
Termination solder
Degree of protection IP67
Connection cross-section 0.25 mm² / AWG 24
Cable outlet 3.5-5.0 mm
Temperature range from/to -40 °C / 85 °C
Mechanical operation > 100 Mating cycles
Weight (g) 10.36
Customs tariff number 85369010
Country of Origin DE

Electrical parameters

Rated voltage 60 V (UL 30 V)
Rated impulse voltage 1500 V
Rated current 4.0 A
Pollution degree 3
Overvoltage category III
Insulating material group III
EMC compliance unshielded

Material

Housing material PA
Contact body material PA
Contact material CuZn (brass)
Contact plating Au (gold)
Locking material CuZn (brass)
REACH SVHC CAS 7439-92-1 (Lead)

Downloads

Additional Information

Device Connector
Type M8 Cable | Male | Straight Circular
Upgrade your connections with the 99-3383-00-04 M8 Male Straight Circular Connector. Designed for durability and reliability, this IP67-rated connector ensures a secure fit with a temperature range of -40°C to 85°C. Perfect for industrial applications, it offers excellent electrical performance with a rated current of 4.0 A and over 100 mating cycles. Enhance your setup with this high-quality connector that combines strength and efficiency.
