BATT 12V26 FBT

• Nominal Voltage : 12V
• Rated Capacity (20hr Rate) : 18Ah
• Dimensions
• Length : 180mm
• Width : 77mm
• Height : 167mm
• Total Height : 167mm
• Weight : 5.13kg

Characteristics

• Capacity 77°F(25°C)
• 20hour rate (0.60 A) : 18.0Ah
• 10hour rate (1.08 A) : 16.2Ah
• 5hour rate (2.04 A) : 15.3Ah
• 1hour rate (7.80 A) : 11.7Ah
• Internal Resistance
• Full Charged, 77°F(25°C) : 15mΩ
• Affected By Temperature (10hr Rate)
• 104°F(40°C) : 102%
• 77°F(25°C) : 100%
• 32°F(0°C) : 85%
• 5°F(-15°C) : 65%
• Self-Discharge 77°F(25°C)
• Capacity after 3 month storage : 90%
• Capacity after 6 month storage : 80%
• Capacity after 9 month storag : 60%

Charge (Constant Voltage)

• Initial Charge Current “LESS” than 5.40A
• Cycle : 14.4–15.0V/77°F(25°C)
• Stand By : 13.5–13.8V/77°F(25°C)
