• Nominal Voltage : 12V
• Rated Capacity (20hr Rate) : 33Ah
• Dimensions
• Length : 7.76 inches (197mm)
• Width : 5.16 inches (131mm)
• Height : 6.19 inches (157mm)
• Total Height : 7.25 inches (184mm)
• Weight : Approx.21.94lbs(9.95kg)

Characteristics

• Capacity 77°F(25°C)
• 20hour rate (1.65 A) : 33.0Ah
• 10hour rate (3.04 A) : 30.4Ah
• 5hour rate (5.61 A) : 28.1Ah
• 1hour rate (21.5 A) : 21.5Ah
• Internal Resistance
• Full Charged, 77°F(25°C) : 7.2mΩ
• Affected By Temperature (10hr Rate)
• 104°F(40°C) : 102%
• 77°F(25°C) : 100%
• 32°F(0°C) : 85%
• 5°F(-15°C) : 65%
• Self-Discharge 77°F(25°C)
• Capacity after 3 month storage : 90%
• Capacity after 6 month storage : 80%
• Capacity after 9 month storag : 60%

Charge (Constant Voltage)

• Initial Charge Current “LESS” than 9.90A
• Cycle : 14.2V–14.5V/77°F(25°C)
• Stand By : 13.4V–13.7V/77°F(25°C)
