• Nominal Voltage : 12V
• Rated Capacity (20hr Rate) : 65Ah
• Dimensions
• Length : 13.74" (349mm)
• Width : 6.54" (166mm)
• Height : 6.85" (174mm)
• Total Height : 6.85" (167mm)
• Weight : Approx. 45.20lbs (20.5kg)

Characteristics

• Capacity 77°F(25°C)
• 20hour rate (3.2 A) : 65.0Ah
• 10hour rate (5.98 A) : 59.8Ah
• 5hour rate (11.05 A) : 55.3Ah
• 1hour rate (42.25 A) : 42.3Ah
• Internal Resistance
• Full Charged, 77°F(25°C) : 6mΩ
• Affected By Temperature (10hr Rate)
• 104°F(40°C) : 102%
• 77°F(25°C) : 100%
• 32°F(0°C) : 85%
• 5°F(-15°C) : 65%
• Self-Discharge 77°F(25°C)
• Capacity after 3 month storage : 90%
• Capacity after 6 month storage : 80%
• Capacity after 9 month storag : 60%

Charge (Constant Voltage)

• Initial Charge Current “LESS” than 19.5A
• Cycle : 14.4–15.0V/77°F(25°C)
• Stand By : 13.5–13.8V/77°F(25°C)
