BC169B

Name: BC169B - Communica [Part No: BC169B]
Brand: Communica
SKU: BC169B
Price: 7.95 ZAR
Availability: InStock

SKU: BC169B

BRAND: Communica

R 9.14_{(inc VAT)}
R 7.95_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Semiconductors

Type: Transistors

Category: NPN General Purpose Transistor

N 20V 20V 100mA 240MN TO92 Transistor

Transistor Silicon NPN

Specifications

Case	TO92
Vbr CBO	30
Vbr CEO	20
Max. PD (W)	500m
C(ob) (F)	7.0p
Derate (Amb) (W/°C)	2.4m
hfe	180
Ic Max. (A)	500m
Icbo Max. @Vcb Max. (A)	15n
Polarity	NPN
Trans. Freq (Hz) Min.	85M
@VCE (test) (V)	5.0
Oper. Temp (°C) Max.	150
@Ic (A)	2.m
Pinout Equivalence Number	3-10
Surface Mounted Yes/No	NO
Maximum Collector Power Dissipation (Pc)	0.3 W
Maximum Collector-Base Voltage \|Vcb\|	20 V
Maximum Collector-Emitter Voltage \|Vce\|	20 V
Maximum Emitter-Base Voltage \|Veb\|	5 V
Maximum Collector Current \|Ic max\|	0.1 A
Max. Operating Junction Temperature (Tj)	150 °C
Collector Capacitance (Cc)	5 pF
Transition Frequency (ft):	85 MHz
Forward Current Transfer Ratio (hFE), MIN	240

Additional Information

Device

Transistor

Discover the BC169B NPN Transistor, designed for optimal performance with a maximum collector current of 500mA and a transition frequency of 85MHz. Ideal for various electronic applications, this reliable transistor ensures efficient power management and durability, operating up to 150°C. Upgrade your projects with this high-quality, versatile component that delivers superior efficiency and reliability.
